5' E34 520i Rear axle support/wheel suspension

Rear axle support/wheel suspension
No. Description Supp. Qty  From   Up To  Part Number Price Notes
01 Trailing arm, left 1 33321133393 $1192.70
01 Trailing arm, right 1 33321133394 $1192.70
02 Set rubber mounting eccentric D=44MM 1 33329058824 $76.91 ENDED
02 Set rubber mounting D=44MM 1 33329061946 $76.91
03 Hex bolt M12X1,5X90 4 33321136406 $10.69
05 Self-locking hex nut M12X1,5-10-PHR 4 07129900047 $0.62
06 Pitman arm 2 33321126476 $119.80 ENDED
06 Pitman arm 2 33321125665
07 Hex bolt M14X1,5X100 2 07119914849 $3.05
08 Washer 15 4 07/1996 33311125916 $0.38 ENDED
08 Washer A15 ZNS3 4 07119905829 $0.74
09 Self-locking hex nut M14X1,5 2 07129922745 $1.04
10 Hex bolt M14X1,5X60 2 07119914816 $2.89
11 Pulse generator, ABS 2 34521181490 $161.61 ENDED
11 Pulse generator 2 34521181456
12 Fillister-head screw M6X12 2 07/1996 07119919913 $0.20 ENDED
12 Fillister-head screw M6X12-ZNNIV SI 2 07/1996 07119905816 ENDED
12 ISA screw M6X12-8.8-ZNNIV 2 07129905867
13 Wave washer B6 2 07119932099 $0.38
14 Cable holder 2 34521179169 $0.50
15 Cable clamp D=6MM 4 63121364431 $0.93
Notes
  • ENDED = the part has been discontinued (no longer available).
