Arbre de transmission, toutes roues for BMW 3 Series E46 325xi (2004)
This Arbre de transmission, toutes roues technical drawing provides a detailed breakdown of the assembly for the 3 Series E46 325xi. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2004.
| N° | Descriptions | Supplément | Qté | A partir de | Jusqu'à | Référence pièce | Prix | Note | ||
|---|---|---|---|---|---|---|---|---|---|---|
| Pour véhicules avec Boîte de vitesses automatique |
S205A=Oui |
|||||||||
| 01 | Arbre de transmission avant | L=718MM | 1 | 03/2003 | 26207525969 | $809.78 | +vieille matière | Shop at ECS Tuning | ||
| Ne convenant qu'avec boîte de vitesses manuelle |
||||||||||
| 02 | Arbre de transmission avant | L=723MM | 1 | 03/2003 | 26207525970 | $809.78 | +vieille matière | Shop at ECS Tuning | ||
| ASSEMBLAGE Autre intervention n'est pas permise |
||||||||||
| 03 | Vis torx avec ailettes | M10X23-10-ZNS3 | 4 | 03/2003 | 26117571956 | $0.73 | Shop at ECS Tuning | |||
| Pour véhicules avec Boîte de vitesses automatique |
S205A=Oui |
|||||||||
| 03 | Vis torx avec ailettes | M10X23-10-ZNS3 | 8 | 03/2003 | 26117571956 | $0.73 | Shop at ECS Tuning | |||
| Ne convenant qu'avec boîte de vitesses manuelle |
||||||||||
| 04 | Vis Torx | M10X42-10.9ZNS3 | 3 | 03/2003 | 26117525945 | $1.83 | arrêté | Shop at ECS Tuning | ||
| 05 | Arbre de transmission arriere | L=1244MM/NV-124 | 1 | 26117502959 | $812.27 | Shop at ECS Tuning | ||||
| uniquement en combinaison avec | ||||||||||
| -- | Bande butyle Ködiplast HV 578-59 | 190X20X8MM | 1 | 83225A1B482 | Shop at ECS Tuning | |||||
| 06 | Vis six pans | M12X1,5X58-ZNS3 | 3 | 26117523709 | $2.73 | Shop at ECS Tuning | ||||
Note
- +vieille matière = consigne de la vieille matière (possibilité de retourner la vieille pièce)
- arrêté = la pièce n'est plus produite.
