K589 (K 1200 RS, K 1200 LT) K 1200 LT 99 (0545,0555) Rear wheel brake, ABS

Rear wheel brake, ABS
No. Description Supp. Qty  From   Up To  Part Number Price Notes
01 Rear brake disc ABS 1 34217711093 $528.58 +core
02 Countersunk head screw M8X20 TUFLOK 2 34212330021 $2.80
03 Brake caliper, rear 1 34217687020 $605.65 +core
04 Vent screw M10 1 34212330310 $10.64
05 Dust cap 1 34211236794 $6.09
06 Shim 0,100MM X 34511458406 $3.07
06 Shim 0,200MM X 34511458407 $3.07
06 Shim 0,300MM X 34511458408 $3.07
06 Shim 0,500MM X 34511458409 $3.07
06 Shim 0,400MM X 34512310338 $3.07
06 Shim 1,000MM X 34512310339 $3.07
06 Shim 0,050MM X 34512310340 $3.07
07 Pulse generator 1 34522331290 $178.14 +core
08 Fillister-head screw M5X14 2 34511458494 $1.74
09 Fit bolt 1 34511457496 $8.27
10 Fit bolt M10X26-8.8 1 34512310887 $6.92
11 Washer ZNS3 1 07119904198 $0.45
12 Brake pads kit 1 34217680375 $68.16
Required for repair
-- Set mounting parts 1 34217652754 $33.73
13 Set mounting parts 1 34217652754 $33.73
14 Repair set brake caliper D=32/34MM 1 34217665377 $129.11
Notes
  • +core = plus core charge (possibility of a return of the old part)
