Skříň převodovky horní for BMW 3 Series E21 323i (1982)
This Skříň převodovky horní technical drawing provides a detailed breakdown of the assembly for the 3 Series E21 323i. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1982.
| Č. | Popis | Doplnění | Poč. | Od | Do | Číslo dílu | Cena | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Kryt horní díl | 1 | 11141276545 | $52.83 | UKONČENO | Shop at ECS Tuning | ||||
| pouze společně s | ||||||||||
| -- | Kryt spodní díl | 1 | 11141271862 | $10.63 | UKONČENO | Shop at ECS Tuning | ||||
| 02 | Šestihranný šroub | M8X25 | 1 | 07119913653 | $0.47 | Shop at ECS Tuning | ||||
| 03 | Pružná podložka | 8,4X15-ZNS3 | 1 | 07119904115 | $0.09 | Shop at ECS Tuning | ||||
| 04 | Šestihranný šroub | M6X22-8.8-ZNS3 | 2 | 07119904505 | $0.38 | Shop at ECS Tuning | ||||
| 05 | Pružná podložka černá | B6-ZN | 2 | 07119932073 | $0.38 | Shop at ECS Tuning | ||||
| 06 | Závěsný hák | 1 | 11141277419 | $4.05 | Shop at ECS Tuning | |||||
| 07 | Ochranné víčko | 1 | 12111364297 | $0.23 | Shop at ECS Tuning | |||||
| 09 | Snímač polohy | 1 | 08/1980 | 12521279695 | $42.52 | Shop at ECS Tuning | ||||
| 10 | Kryt horní díl | 1 | 11141276545 | $52.83 | UKONČENO | Shop at ECS Tuning | ||||
| pouze společně s | ||||||||||
| -- | Závěsný hák | 1 | 11141277419 | $4.05 | Shop at ECS Tuning | |||||
| 11 | Kryt spodní díl | 1 | 11141271862 | $10.63 | UKONČENO | Shop at ECS Tuning | ||||
| 12 | Pryžové těsnění | 1 | 11141269557 | $12.31 | Shop at ECS Tuning | |||||
| 13 | Závěsný hák | 1 | 11141277419 | $4.05 | Shop at ECS Tuning | |||||
Notes
- Ukončeno = Díl se již nevyrábí.
