Kliková skříň-ventilace/odlučovač oleje for BMW 3 Series E30 320is (1990)
This Kliková skříň-ventilace/odlučovač oleje technical drawing provides a detailed breakdown of the assembly for the 3 Series E30 320is. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1990.
| Č. | Popis | Doplnění | Poč. | Od | Do | Číslo dílu | Cena | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Odlučovač oleje | 1 | 10/1986 | 11152241124 | $45.06 | Shop at ECS Tuning | ||||
| 02 | Přídržný úhelník | 1 | 10/1986 | 11151311838 | $3.38 | UKONČENO | Shop at ECS Tuning | |||
| 03 | Šestihranný šroub | M8X60-ZNNIV SI | 1 | 10/1986 | 07119905974 | Shop at ECS Tuning | ||||
| 03 | Šroub s válcovou hlavou | M8X60 | 1 | 10/1986 | 07119919989 | $0.75 | UKONČENO | Shop at ECS Tuning | ||
| 04 | Pryžové ložisko | 1 | 10/1986 | 13411705564 | $2.40 | +core | Shop at ECS Tuning | |||
| 05 | Šestihranný šroub | M10X17,5 | 2 | 10/1986 | 24001421067 | $0.75 | Shop at ECS Tuning | |||
| 06 | hadicová spona | L32-38 | 1 | 10/1986 | 07129952115 | $1.27 | Shop at ECS Tuning | |||
| 07 | Hadicové vedení | 1 | 10/1986 | 11151310814 | $34.24 | Shop at ECS Tuning | ||||
| 08 | Držák hadice | D=18/D=25 | 1 | 10/1986 | 12511309471 | $1.50 | Shop at ECS Tuning | |||
| 09 | hadicová spona | L28-33 | 4 | 10/1986 | 07129952113 | $0.96 | Shop at ECS Tuning | |||
| 10 | Hadicové vedení | 1 | 10/1986 | 11151310811 | $25.24 | Shop at ECS Tuning | ||||
| 11 | hadicová spona | L12-15 | 2 | 10/1986 | 07129952104 | $1.18 | Shop at ECS Tuning | |||
| 12 | Hadice | 1 | 10/1986 | 11151311839 | $25.24 | Shop at ECS Tuning | ||||
| 13 | Hrdlo šroubení | L=114MM | 1 | 10/1986 | 11131310726 | $74.40 | Shop at ECS Tuning |
Notes
- Ukončeno = Díl se již nevyrábí.
- +core = plus poplatek za střední část (možnost navrácení původního dílu)
