Rozvod ventilů-vstupní/výstupní ventil for BMW 1502-2002tii 2002 (1975)
This Rozvod ventilů-vstupní/výstupní ventil technical drawing provides a detailed breakdown of the assembly for the 1502-2002tii 2002. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1975.
| Č. | Popis | Doplnění | Poč. | Od | Do | Číslo dílu | Cena | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Vedení ventilu | +0,10MM | 8 | 11121266760 | $11.54 | UKONČENO, SI 110288843 | Shop at ECS Tuning | |||
| 01 | Vedení ventilu | +0,20MM D=7,9MM | 8 | 11121266761 | $9.94 | UKONČENO | Shop at ECS Tuning | |||
| 01 | Vedení ventilu | 14,40MM(+0,2) | 8 | 11121713407 | UKONČENO | Shop at ECS Tuning | ||||
| 01 | Vedení ventilu | 14,40MM(+0,2) | 8 | 11121713407 | UKONČENO | Shop at ECS Tuning | ||||
| pouze společně s | ||||||||||
| -- | Těsnění ventilového dříku | D=10,8MM | 8 | 11341273501 | $23.16 | UKONČENO | Shop at ECS Tuning | |||
| 01 | Vedení ventilu | +0,30MM | 8 | 11121266762 | UKONČENO, SI 110288843 | Shop at ECS Tuning | ||||
| 01 | Vedení ventilu | 14,30MM(+0,1) | 8 | 11121713406 | UKONČENO | Shop at ECS Tuning | ||||
| pouze společně s | ||||||||||
| -- | Těsnění ventilového dříku | D=10,8MM | 8 | 11341273501 | $23.16 | UKONČENO | Shop at ECS Tuning | |||
| 01 | Vedení ventilu | 14,30MM(+0,1) | 8 | 11121713406 | UKONČENO | Shop at ECS Tuning | ||||
| 02 | Závitová vložka | M6 | 1 | 11121744337 | $1.68 | UKONČENO | Shop at ECS Tuning | |||
| 03 | Připojovací kus | M22X1,5/22MM | 1 | 11121250746 | $21.46 | Shop at ECS Tuning | ||||
| 04 | Těsnicí kroužek | A22X27-AL | 1 | 07119963355 | $0.36 | Shop at ECS Tuning | ||||
| 05 | Redukce | M22X1,4/M36X1,5 | 1 | 03/1971 | 07/1977 | 11121250745 | $19.50 | UKONČENO | Shop at ECS Tuning | |
| 06 | Těsnicí kroužek | A36X42-AL | 1 | 03/1971 | 07/1977 | 07119963467 | $0.62 | UKONČENO | Shop at ECS Tuning | |
Notes
- Ukončeno = Díl se již nevyrábí.
- SI = Service-Information (Servisní informace)
