Chladič for BMW 2500-3.3Li 3.0Si (1975)
This Chladič technical drawing provides a detailed breakdown of the assembly for the 2500-3.3Li 3.0Si. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1975.
| Č. | Popis | Doplnění | Poč. | Od | Do | Číslo dílu | Cena | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 03 | hadicová spona | L12-15 | 2 | 09/1971 | 02/1977 | 07129952104 | $1.18 | Shop at ECS Tuning | ||
| 04 | Hadice | 1 | 09/1973 | 02/1977 | 11531266475 | $10.92 | Shop at ECS Tuning | |||
| Fg -> B | ||||||||||
| 09 | Hadice | 1 | 09/1974 | 07/1976 | 11611261816 | $16.15 | Shop at ECS Tuning | |||
| 10 | hadicová spona | L18-24 | 3 | 09/1973 | 02/1977 | 07129952109 | $1.07 | Shop at ECS Tuning | ||
| Fg -> B | ||||||||||
| 11 | Rozdělovač | 1 | 09/1974 | 07/1976 | 11611261818 | $1.62 | UKONČENO | Shop at ECS Tuning | ||
| 12 | Hadice | 1 | 09/1971 | 02/1977 | 11611256505 | $30.30 | Shop at ECS Tuning | |||
| -> Fg A | ||||||||||
| 12 | Hadice | 1 | 09/1973 | 02/1977 | 11611259414 | $25.24 | Shop at ECS Tuning | |||
| Fg -> B | ||||||||||
| 13 | hadicová spona | L23-29 | 3 | 12/1995 | 07129952111 | $0.93 | UKONČENO | Shop at ECS Tuning | ||
| 13 | hadicová spona | L16-30 | 3 | 64218367179 | $1.07 | Shop at ECS Tuning | ||||
| 14 | Hadice | 1 | 09/1974 | 07/1976 | 11611261204 | $10.25 | Shop at ECS Tuning | |||
| 15 | Těsnění bez azbestu | 1 | 11611730239 | $4.80 | UKONČENO | Shop at ECS Tuning | ||||
| 17 | Šestihranný šroub | M6X22-8.8-ZNS3 | 2 | 07119904505 | $0.38 | Shop at ECS Tuning | ||||
Notes
- Ukončeno = Díl se již nevyrábí.
