Výfukové potrubí zadní for BMW MINI R50 Cooper (2000)
This Výfukové potrubí zadní technical drawing provides a detailed breakdown of the assembly for the MINI R50 Cooper. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2000.
| Č. | Popis | Doplnění | Poč. | Od | Do | Číslo dílu | Cena | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| i | Není vhodné k John Cooper Works Tuning Kit; další informace viz HG11 FG95 |
|||||||||
| 01 | Výfukové potrubí zadní | 1 | 04/2004 | 18307537083 | $505.83 | Shop at ECS Tuning | ||||
| pouze společně s | ||||||||||
| -- | Tepelná izolace nádrž | 1 | 04/2004 | 51487124372 | $56.70 | Shop at ECS Tuning | ||||
| 02 | Ploché těsnění | 1 | 18111170941 | $8.46 | Shop at ECS Tuning | |||||
| Oprava nutná | ||||||||||
| -- | Šestihranná matice s přírubou | M10 | 2 | 07130757758 | $1.09 | Shop at ECS Tuning | ||||
| 03 | Šestihranná matice s přírubou | M10 | 2 | 07130757758 | $1.09 | Shop at ECS Tuning | ||||
| 04 | Díl nelze koupit zvlášť | 1 | 00000000000 | Shop at ECS Tuning | ||||||
| 06 | Spojovací nosník | 1 | 51717037919 | $38.82 | +core | Shop at ECS Tuning | ||||
| 07 | Šestihranný šroub s přírubou | 6 | 41007058312 | $1.35 | Shop at ECS Tuning | |||||
| 08 | Pryžové ložisko | 2 | 18100392258 | $21.41 | Shop at ECS Tuning | |||||
| 09 | Šestihranný šroub | M6X16-8.8-ZNS | 2 | 05/2005 | 07119913015 | $0.60 | Shop at ECS Tuning | |||
| 10 | Spona dolní | 1 | 18201490024 | $10.70 | Shop at ECS Tuning | |||||
| 11 | Spona horní | 1 | 18207520245 | $53.32 | Shop at ECS Tuning | |||||
| 12 | Šroub | 2 | 07130782600 | $0.89 | Shop at ECS Tuning | |||||
| 13 | Pryžový kroužek | 2 | 12/2001 | 18207519253 | $21.41 | Shop at ECS Tuning | ||||
| 14 | Šestihranná matice | M8-ZNS3 | 4 | 07119904024 | $0.20 | Shop at ECS Tuning | ||||
| 15 | Držák dolní pro tlumič vibrací | 1 | 09/2001 | 18107515189 | $32.46 | UKONČENO | Shop at ECS Tuning | |||
| 16 | Držák horní pro tlumič vibrací | 1 | 09/2001 | 18107515187 | $32.90 | UKONČENO | Shop at ECS Tuning | |||
| 17 | Šestihranný šroub | M8X1,25X20-8.8 | 1 | 09/2001 | 18207519892 | $3.27 | UKONČENO | Shop at ECS Tuning | ||
| 18 | Tlumič vibrací | 2 | 09/2001 | 18107515190 | $39.29 | UKONČENO, +core | Shop at ECS Tuning | |||
| 19 | Okno | 2 | 09/2001 | 18207516549 | $1.80 | UKONČENO | Shop at ECS Tuning | |||
| 20 | Koncovka trubky chrom | 80MM | 1 | 82122210098 | Shop at ECS Tuning | |||||
| 21 | Závitový čep | 2 | 18107520438 | $3.32 | Shop at ECS Tuning | |||||
Notes
- +core = plus poplatek za střední část (možnost navrácení původního dílu)
- Ukončeno = Díl se již nevyrábí.
