Uložení motoru for BMW 7 Series G70 740i (2025)
This Uložení motoru technical drawing provides a detailed breakdown of the assembly for the 7 Series G70 740i. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2025.
| Č. | Popis | Doplnění | Poč. | Od | Do | Číslo dílu | Cena | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Nosník motoru pravý | 1 | 22119894898 | Shop at ECS Tuning | ||||||
| 02 | Nosník motoru levý | 1 | 22119894897 | Shop at ECS Tuning | ||||||
| 03 | Šroub s válc.hlavou s vnit.šestihranem | BM10X40-U1-8.8- | 8 | 07119908517 | Shop at ECS Tuning | |||||
| 04 | Motorové ložisko pravé | 1 | 22119894882 | Shop at ECS Tuning | ||||||
| 05 | Motorové ložisko levé | 1 | 22119894881 | Shop at ECS Tuning | ||||||
| 06 | Šroub válc.hlava vnit.šestihr.samojist. | M12X1.5X40.5MKL | 2 | 07148869310 | Shop at ECS Tuning | |||||
| 07 | Šestihranný šroub | 2 | 07148866278 | Shop at ECS Tuning | ||||||
| 08 | Šestihranný šroub s podložkou | M8X90 ZNNIV SI | 4 | 07119907017 | Shop at ECS Tuning |
See Also
Frequently Asked Questions
- What assembly is shown in the BMW 7 Series G70 740i Uložení motoru?
- This technical diagram illustrates the Uložení motoru within the Zavěšení motoru/převodovky group for the 7 Series G70 740i produced during 2025. It provides a detailed exploded view of the components, identifying key parts such as the Nosník motoru pravý (Part #22119894898).
- Which models use the hardware listed in this Uložení motoru?
- The hardware and components featured in the Uložení motoru are specific to the 7 Series G70 740i produced during 2025. These technical specifications ensure that parts like the Nosník motoru pravý (22119894898) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Uložení motoru assembly?
- Each item in the Uložení motoru corresponds to the numbered list below the illustration. For the 7 Series G70 740i, you can identify the Nosník motoru pravý by locating its position on the schematic, which then links to the official BMW part number 22119894898 for the Zavěšení motoru/převodovky section.
