Strop karoserie for BMW MINI F66 JCW
This Strop karoserie technical drawing provides a detailed breakdown of the assembly for the MINI F66 JCW. It includes part names, part numbers and all associated mounting hardware.
| Č. | Popis | Doplnění | Poč. | Od | Do | Číslo dílu | Cena | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| Pro vozidla s Zabezpečovací systém a Panoramatická střecha elektrická a KAMERA INTERIÉRU VOZIDLA |
S302A=Ne S402A=Ne S4NRA=Ne |
|||||||||
| 01 | Strop karoserie | ANTHRAZIT | 1 | 51445A33992 | NoS | Shop at ECS Tuning | ||||
| Pro vozidla s Zabezpečovací systém a Panoramatická střecha elektrická a KAMERA INTERIÉRU VOZIDLA |
S302A=Ano S402A=Ne S4NRA=Ano |
|||||||||
| 02 | Strop karoserie | ANTHRAZIT | 1 | 51445A33994 | Shop at ECS Tuning | |||||
| Pro vozidla s Zabezpečovací systém a Panoramatická střecha elektrická a KAMERA INTERIÉRU VOZIDLA |
S302A=Ano S402A=Ne S4NRA=Ne |
|||||||||
| 02 | Strop karoserie | ANTHRAZIT | 1 | 51445A33994 | Shop at ECS Tuning | |||||
| Pro vozidla s Zabezpečovací systém a Panoramatická střecha elektrická a KAMERA INTERIÉRU VOZIDLA |
S302A=Ne S402A=Ne S4NRA=Ano |
|||||||||
| 02 | Strop karoserie | ANTHRAZIT | 1 | 51445A33994 | NoS | Shop at ECS Tuning | ||||
| Pro vozidla s Panoramatická střecha elektrická a Strop karoserie antracit |
S402A=Ano S4AAA=Ano |
|||||||||
| 03 | Strop karoserie panoramatická střecha | ANTHRAZIT | 1 | 51445A33996 | NoS | Shop at ECS Tuning | ||||
| 04 | Rozpěrný nýt | D=7,5MM | 2 | 51481915964 | $0.43 | Shop at ECS Tuning | ||||
| Pro vozidla s Strop karoserie antracit |
S4AAA=Ano |
|||||||||
| 05 | Rozpěrný nýt | CARBON BLACK | 2 | 51442756902 | $0.65 | Shop at ECS Tuning | ||||
Notes
- NoS = No Stock (Díl není centrálně skladován.)
