Sedadlo zadní vak na lyže for BMW 7 Series F02 LCI 740Li (2015)
This Sedadlo zadní vak na lyže technical drawing provides a detailed breakdown of the assembly for the 7 Series F02 LCI 740Li. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2015.
| Č. | Popis | Doplnění | Poč. | Od | Do | Číslo dílu | Cena | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Vak na lyže základní | 1 | 52207213421 | $394.45 | Shop at ECS Tuning | |||||
| Pro vozidla s Komfortní sedadlo zadní elektricky nast. |
S460A=Ano |
|||||||||
| 01 | Vak na lyže komfort | 1 | 52207213422 | Shop at ECS Tuning | ||||||
| 02 | Lišta vak na lyže přední | SCHWARZ | 1 | 52209165789 | $15.66 | Shop at ECS Tuning | ||||
| 03 | Lišta vak na lyže zadní | BASALTGRAU | 1 | 52207233045 | +core | Shop at ECS Tuning | ||||
| 03 | Lišta vak na lyže zadní | SCHWARZ | 1 | 52207233046 | $63.73 | +core | Shop at ECS Tuning | |||
| Pro vozidla s Chladicí box |
S791A=Ano |
|||||||||
| 03 | Clona chladicí box | SCHWARZ | 1 | 52207903902 | Shop at ECS Tuning | |||||
| 04 | Šroub s čočkovou hlavou s nástavcem | 4 | 07146977741 | $0.25 | Shop at ECS Tuning | |||||
Notes
- +core = plus poplatek za střední část (možnost navrácení původního dílu)
