Kondenzátor klimatizace/pomocný ventil. for BMW 5 Series E39 530i (2003)
This Kondenzátor klimatizace/pomocný ventil. technical drawing provides a detailed breakdown of the assembly for the 5 Series E39 530i. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2003.
| Č. | Popis | Doplnění | Poč. | Od | Do | Číslo dílu | Cena | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Kondenzátor | 1 | 09/1997 | 64538378438 | $540.42 | Shop at ECS Tuning | ||||
| 01 | Kondenzátor | 1 | 64538378438 | $540.42 | Shop at ECS Tuning | |||||
| 02 | Tlačný rám | 1 | 05/1998 | 64548380782 | $124.39 | Shop at ECS Tuning | ||||
| 03 | Šestihranná matice s podložkou | M8 | 4 | 22316760944 | $0.38 | Shop at ECS Tuning | ||||
| 04 | Pouzdro | 4 | 64538361938 | $4.40 | Shop at ECS Tuning | |||||
| 05 | Tlačný ventilátor | 1 | 09/1998 | 64546921395 | $374.55 | Shop at ECS Tuning | ||||
| 06 | Ochranná mřížka pomocný ventilátor horní | 1 | 64548361937 | $13.65 | Shop at ECS Tuning | |||||
| 07 | Ochranná mřížka pomocný ventilátor dolní | 1 | 64548371347 | $13.65 | Shop at ECS Tuning | |||||
| 09 | Těsnění tlačný rám pravý | 1 | 64548387522 | $15.77 | Shop at ECS Tuning |
See Also
Frequently Asked Questions
- What assembly is shown in the BMW 5 Series E39 530i Kondenzátor klimatizace/pomocný ventil.?
- This technical diagram illustrates the Kondenzátor klimatizace/pomocný ventil. within the Topení a klimatizace group for the 5 Series E39 530i produced during 2003. It provides a detailed exploded view of the components, identifying key parts such as the Kondenzátor (Part #64538378438).
- Which models use the hardware listed in this Kondenzátor klimatizace/pomocný ventil.?
- The hardware and components featured in the Kondenzátor klimatizace/pomocný ventil. are specific to the 5 Series E39 530i produced during 2003. These technical specifications ensure that parts like the Kondenzátor (64538378438) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Kondenzátor klimatizace/pomocný ventil. assembly?
- Each item in the Kondenzátor klimatizace/pomocný ventil. corresponds to the numbered list below the illustration. For the 5 Series E39 530i, you can identify the Kondenzátor by locating its position on the schematic, which then links to the official BMW part number 64538378438 for the Topení a klimatizace section.
