Oddělovací prvek for BMW 5 Series E61 530d (2005)

This Oddělovací prvek technical drawing provides a detailed breakdown of the assembly for the 5 Series E61 530d. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2005.

Oddělovací prvek
Č. Popis Doplnění Poč.  Od   Do  Číslo dílu Cena Notes
VALUE REPAIR PARTS!
Výrobek významně snižuje
náklady na opravu. Primární díl již není
nutné měnit.
01 Oddělovací prvek VALUE PARTS 1 18307793967 Shop at ECS Tuning
Dodržujte prosím návod k opravě.
Přesně obnovte polohu!
Vyměňte nástavby a těsnění!
02 Šestihranná matice M10 2 18301737774 $1.65 Shop at ECS Tuning
03 držák katalyzátoru u motoru 1 18207794961 Shop at ECS Tuning
04 Vzpěra 2 18207789884 Shop at ECS Tuning
05 Matice s nákružkem M8-8-SC-ZNNIV 6 07119906089 $0.32 Shop at ECS Tuning
06 Upínací pás D=70,6 X 31,8MM 1 18307791587 $15.83 Shop at ECS Tuning
07 Pryžové ložisko 1 18211437236 Shop at ECS Tuning
08 Šroub s válcovou hlavou M8X35-10.9-ZNS3 4 07119906650 $0.87 Shop at ECS Tuning
09 Matice s nákružkem samojistící M8-10 ZNS3 4 07119905374 Shop at ECS Tuning
10 Těsnění 1 18307789904 Shop at ECS Tuning

See Also

Frequently Asked Questions

What assembly is shown in the BMW 5 Series E61 530d Oddělovací prvek?
This technical diagram illustrates the Oddělovací prvek within the Value Parts&Packages Service and Repair group for the 5 Series E61 530d produced during 2005. It provides a detailed exploded view of the components, identifying key parts such as the Oddělovací prvek (Part #18307793967).
Which models use the hardware listed in this Oddělovací prvek?
The hardware and components featured in the Oddělovací prvek are specific to the 5 Series E61 530d produced during 2005. These technical specifications ensure that parts like the Oddělovací prvek (18307793967) are correctly matched to the vehicle's structural and mechanical requirements.
How do I find specific parts within the Oddělovací prvek assembly?
Each item in the Oddělovací prvek corresponds to the numbered list below the illustration. For the 5 Series E61 530d, you can identify the Oddělovací prvek by locating its position on the schematic, which then links to the official BMW part number 18307793967 for the Value Parts&Packages Service and Repair section.
