Kühlsystem-Kühlmittelschläuche for BMW MINI F56 JCW
This Kühlsystem-Kühlmittelschläuche technical drawing provides a detailed breakdown of the assembly for the MINI F56 JCW. It includes part names, part numbers and all associated mounting hardware.
| Nr. | Beschreibung | Erläuterungen | Anzahl | Von | Bis | Teilenummer | Preis | Ergänzungen | ||
|---|---|---|---|---|---|---|---|---|---|---|
| i | Für Fahrzeuge mit Automatikgetriebe oder Sport-Automatik Getriebe |
S205A=Ja S2TBA=Ja |
||||||||
| 01 | Schlauch Kühler-Motor | 1 | 17127617363 | Shop at ECS Tuning | ||||||
| 02 | Schlauch Kühler unten-Thermostat | 1 | 17127617368 | Shop at ECS Tuning | ||||||
| 03 | Leitung Zylinderkopf-Ausgleichsbehälter | 1 | 17127646896 | Shop at ECS Tuning | ||||||
| 04 | Rohr Ausgleichsbehälter-Zylinderkopf | 1 | 17127646898 | Shop at ECS Tuning | ||||||
| 05 | Kabelklemme | 2 | 08/2024 | 11787549563 | $1.04 | Shop at ECS Tuning | ||||
| 05 | Clip | 15-19 | 2 | 07147568538 | $3.49 | Shop at ECS Tuning | ||||
| 06 | Sechsrundschraube | BM6X16-U1-8.8- | 2 | 07119908518 | Shop at ECS Tuning | |||||
| 07 | Rohr Kühler-Ausgleichsbehälter | 1 | 17127617366 | Shop at ECS Tuning | ||||||
| 08 | Schlauch Wärmetauscher-Kühlmittelrohr | 1 | 17127640014 | Shop at ECS Tuning | ||||||
| 09 | Leitung Pumpe-Abgasturbolader-Wärmet.- | 1 | 17127617377 | Shop at ECS Tuning | ||||||
| 10 | Kühlmittelrohr | 1 | 17128606015 | Shop at ECS Tuning | ||||||
| 11 | Schlauch Getriebeöl Wärmetauscher | 1 | 17127617381 | Shop at ECS Tuning | ||||||
| 12 | Leitung Wasserpumpe-elektr. Wasserpumpe | 1 | 17127617380 | Shop at ECS Tuning | ||||||
| 13 | Schlauchhalter | 1 | 17127615464 | Shop at ECS Tuning | ||||||
| 15 | Temperatursensor Kühlmittel | 1 | 13621433077 | $25.03 | Shop at ECS Tuning | |||||
