Verglasung Anbauteile for BMW 5 Series E28 524td (1986)
This Verglasung Anbauteile technical drawing provides a detailed breakdown of the assembly for the 5 Series E28 524td. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1986.
| Nr. | Beschreibung | Erläuterungen | Anzahl | Von | Bis | Teilenummer | Preis | Ergänzungen | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Frontscheibendichtung | 1 | 51311822185 | $108.49 | Shop at ECS Tuning | |||||
| 02 | Zierleiste oben | 1 | 51311820622 | $36.11 | Shop at ECS Tuning | |||||
| 02 | Zierleiste oben | SCHWARZ | 1 | 51311959969 | $69.31 | Shop at ECS Tuning | ||||
| 03 | Zierleiste unten | 1 | 51311817451 | $65.00 | Shop at ECS Tuning | |||||
| 03 | Zierleiste unten | SCHWARZ | 1 | 51311959726 | $70.40 | Entfallen | Shop at ECS Tuning | |||
| 04 | Eckblende links | 1 | 51311820661 | $5.45 | Entfallen | Shop at ECS Tuning | ||||
| 04 | Eckblende links | SCHWARZ | 1 | 51311959987 | $6.55 | Entfallen | Shop at ECS Tuning | |||
| 05 | Eckblende rechts | 1 | 51311820662 | $5.70 | Entfallen | Shop at ECS Tuning | ||||
| 05 | Eckblende rechts | SCHWARZ | 1 | 51311959988 | $6.55 | Shop at ECS Tuning | ||||
| 06 | Heckscheibendichtung | 1 | 51311820485 | $122.15 | Shop at ECS Tuning | |||||
| 07 | Zierleiste | 2 | 51311820624 | $30.70 | Shop at ECS Tuning | |||||
| 07 | Zierleiste | SCHWARZ | 2 | 51311959997 | $23.64 | Entfallen | Shop at ECS Tuning | |||
| 08 | Eckblende | 2 | 51311820269 | $5.45 | Shop at ECS Tuning | |||||
| 08 | Eckblende | SCHWARZ | 2 | 51311959999 | $5.20 | Shop at ECS Tuning | ||||
| 09 | Eckblende rechts | 1 | 51311820660 | $5.45 | Shop at ECS Tuning | |||||
| 09 | Eckblende rechts | SCHWARZ | 1 | 51311961252 | $5.45 | Shop at ECS Tuning | ||||
| 10 | Zierleiste unten | 1 | 51311817452 | $65.00 | Entfallen | Shop at ECS Tuning | ||||
| 10 | Zierleiste unten | SCHWARZ | 1 | 51311959998 | $70.40 | Entfallen | Shop at ECS Tuning | |||
| 11 | Zierleiste oben | 1 | 51311820623 | $29.79 | Shop at ECS Tuning | |||||
| 11 | Zierleiste oben | SCHWARZ | 1 | 51311959980 | $69.31 | Shop at ECS Tuning | ||||
| 12 | Eckblende links | 1 | 51311820659 | $5.45 | Entfallen | Shop at ECS Tuning | ||||
| 12 | Eckblende links | SCHWARZ | 1 | 51311961251 | $5.45 | Shop at ECS Tuning |
Ergänzungen
- Entfallen = nicht mehr lieferbar.
