Anbauteile Motorraum for BMW MINI R56 Cooper (2007)
This Anbauteile Motorraum technical drawing provides a detailed breakdown of the assembly for the MINI R56 Cooper. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2007.
| Nr. | Beschreibung | Erläuterungen | Anzahl | Von | Bis | Teilenummer | Preis | Ergänzungen | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Verkleidung Stirnwand Unterteil | 1 | 51712756275 | $25.58 | Shop at ECS Tuning | |||||
| 02 | Verkleidung Stirnwand Oberteil | 1 | 51717293131 | Shop at ECS Tuning | ||||||
| 03 | Kunststoffhutmutter mit Scheibe | D=18MM | 10 | 08/2013 | 51161943122 | $0.39 | Shop at ECS Tuning | |||
| 03 | Kunststoffmutter Grobgewindebolzen | M6 | 10 | 07147336362 | Shop at ECS Tuning | |||||
| 04 | Tülle | 1 | 51712751609 | $3.75 | Shop at ECS Tuning | |||||
| 05 | Spreizniet | D = 6MM | 1 | 51111908077 | $0.30 | Shop at ECS Tuning | ||||
| 06 | Abdeckung | 1 | 51712755865 | $13.75 | Shop at ECS Tuning | |||||
| 07 | Wasserablauftülle | 2 | 05/2012 | 51712751607 | $4.41 | Shop at ECS Tuning |
