Verkleidung Instrumententafel for BMW MINI R56 Cooper (2007)
This Verkleidung Instrumententafel technical drawing provides a detailed breakdown of the assembly for the MINI R56 Cooper. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2007.
| Nr. | Beschreibung | Erläuterungen | Anzahl | Von | Bis | Teilenummer | Preis | Ergänzungen | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Halter Instrumententafel unten | 3 | 51452752757 | Shop at ECS Tuning | ||||||
| 03 | Halter Instrumententafel | 1 | 51452752758 | Shop at ECS Tuning | ||||||
| 05 | Instrumententafel Unterteil | 1 | 02/2008 | 51452752761 | $144.15 | Entfallen | Shop at ECS Tuning | |||
| 06 | Funktionsträger Mittelkonsole | 1 | 08/2010 | 51452752777 | $93.68 | Entfallen | Shop at ECS Tuning | |||
| 07 | Verriegelung Handschuhkasten | 1 | 51452752778 | $20.42 | Shop at ECS Tuning | |||||
| 08 | Torxschraube mit Bund | 6X20 | 33 | 51452756345 | $0.57 | Shop at ECS Tuning | ||||
| 09 | Clip | 51 | 51452756285 | $0.35 | Shop at ECS Tuning | |||||
| 10 | Linsenblechschraube mit Bund | ISA ST4,2X16 | 60 | 07147136006 | $0.18 | Shop at ECS Tuning | ||||
| 11 | Schraube | 3 | 51452756347 | $0.57 | Shop at ECS Tuning | |||||
| 12 | C-Clip Mutter | 5 | 07146988451 | $0.36 | Shop at ECS Tuning | |||||
| 13 | Einsteckbefestiger Funktionsträger | 4 | 51169281633 | Shop at ECS Tuning |
Ergänzungen
- Entfallen = nicht mehr lieferbar.
