CD Wechsler / Halter for BMW MINI R56 Cooper (2007)
This CD Wechsler / Halter technical drawing provides a detailed breakdown of the assembly for the MINI R56 Cooper. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2007.
| Nr. | Beschreibung | Erläuterungen | Anzahl | Von | Bis | Teilenummer | Preis | Ergänzungen | ||
|---|---|---|---|---|---|---|---|---|---|---|
| i | Bei Tausch des CD-Wechslers müssen die seitlichen Führungselemente entfernt werden. |
|||||||||
| 01 | RP REMAN CD-Wechsler | 1 | 08/2010 | 65129242666 | Entfallen | Shop at ECS Tuning | ||||
| 01 | CD Wechsler | 1 | 08/2010 | 65129230680 | Entfallen, +Pfand | Shop at ECS Tuning | ||||
| 02 | Abdeckkappe | 1 | 08/2010 | 61136905200 | $3.68 | Shop at ECS Tuning | ||||
| nur in Verbindung mit | ||||||||||
| -- | Buchsenkontakt MQS mit Kabel | 0,2- 0,5 QMM | 4 | 08/2010 | 61130005197 | $1.65 | Shop at ECS Tuning | |||
| -- | Buchsenkontakt MQS mit Kabel | 0,5-0,75 MM² AG | 4 | 08/2010 | 61130056960 | Shop at ECS Tuning | ||||
| -- | Buchsengehäuse | 1 | 08/2010 | 61136901844 | $3.42 | Shop at ECS Tuning | ||||
| -- | Lichtwellenleiter Umgehäuse | 2POL. /SCHWARZ | 1 | 08/2010 | 61138387214 | $1.83 | Shop at ECS Tuning | |||
| 03 | Halter CD-Wechsler | 1 | 08/2010 | 51452752894 | $39.68 | +Pfand | Shop at ECS Tuning | |||
| 04 | Linsenschraube mit Bund | 2 | 08/2010 | 07149151777 | $0.47 | Shop at ECS Tuning | ||||
Ergänzungen
- Entfallen = nicht mehr lieferbar.
- +Pfand = plus Altteilepfand (Möglicherweise muss das Altteil im Austausch abgegeben werden)
