Airbag for BMW MINI F66 JCW
This Airbag technical drawing provides a detailed breakdown of the assembly for the MINI F66 JCW. It includes part names, part numbers and all associated mounting hardware.
| Nr. | Beschreibung | Erläuterungen | Anzahl | Von | Bis | Teilenummer | Preis | Ergänzungen | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Airbageinheit Beifahrerseite | 1 | 72125A3F110 | Shop at ECS Tuning | ||||||
| 01 | Airbageinheit Beifahrerseite | 1 | 72125A42F78 | Shop at ECS Tuning | ||||||
| 02 | Linsenschraube | 6 | 07149272649 | Shop at ECS Tuning | ||||||
| 03 | Kopfairbag links | 1 | 72125A2A5A3 | Shop at ECS Tuning | ||||||
| 03 | Kopfairbag rechts | 1 | 72125A2A5A4 | Shop at ECS Tuning | ||||||
| 03 | Kopfairbag links | 1 | 72125A7CBA5 | Shop at ECS Tuning | ||||||
| 04 | Blindniet | 6 | 07147265827 | Shop at ECS Tuning | ||||||
| 05 | Seitenairbag Sitz vorne links | 1 | 72125A2EE97 | Shop at ECS Tuning | ||||||
| 05 | Seitenairbag Sitz vorne rechts | 1 | 72125A2EE98 | Shop at ECS Tuning | ||||||
| Für Fahrzeuge mit Zusatzumfang EU-spezifisch |
S230A=Ja |
|||||||||
| 06 | Center-Airbag rechts | 1 | 72125A2EEA8 | NoS | Shop at ECS Tuning | |||||
| Seitenairbag Sitz vorn | ||||||||||
| 07 | Sechskantmutter | M6-8-ZNS3 | 2 | 07119902751 | $0.56 | Shop at ECS Tuning | ||||
| Center-Airbag | ||||||||||
| 07 | Sechskantmutter | M6-8-ZNS3 | 2 | 07119902751 | $0.56 | Shop at ECS Tuning | ||||
| Für Fahrzeuge mit Länderausführung Japan |
L807A=Ja |
|||||||||
| 08 | Knieairbag rechts | 1 | 72125A470C2 | NoS | Shop at ECS Tuning | |||||
| 08 | Knieairbag links | 1 | 72125A713A6 | NoS | Shop at ECS Tuning | |||||
| 09 | Linsenschraube | ISA M6X16 ZN SW | 4 | 07149165429 | $0.45 | Shop at ECS Tuning | ||||
| Für Fahrzeuge mit Länderausführung Japan und Zusatzumfang EU-spezifisch |
L807A=Nein S230A=Ja |
|||||||||
| 10 | Seitenairbag Sitz hinten links | 1 | 72125A2EEA5 | Shop at ECS Tuning | ||||||
| 10 | Seitenairbag Sitz hinten rechts | 1 | 72125A2EEA6 | Shop at ECS Tuning | ||||||
| Seitenairbag Sitz hinten | ||||||||||
| 11 | Kleinteile Airbag | 1 | 52205A32E70 | Shop at ECS Tuning | ||||||
Ergänzungen
- NoS = No Stock
