Einzelteile SA 630 Gepäckraum for BMW 5 Series E39 523i (2000)
This Einzelteile SA 630 Gepäckraum technical drawing provides a detailed breakdown of the assembly for the 5 Series E39 523i. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2000.
| Nr. | Beschreibung | Erläuterungen | Anzahl | Von | Bis | Teilenummer | Preis | Ergänzungen | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Verbindungskabel Autotelefon | SIEMENS BIT II | 1 | 61126907786 | Entfallen | Shop at ECS Tuning | ||||
| Für Fahrzeuge mit Spracheingabe |
S620A=Ja |
|||||||||
| 01 | Verbindungskabel Autotelefon | SIEMENS BIT II | 1 | 61126907788 | Entfallen | Shop at ECS Tuning | ||||
| Für Fahrzeuge mit Bordmonitor mit TV oder Navigationssystem Professional |
S602A=Ja S609A=Ja |
|||||||||
| 01 | Verbindungskabel Autotelefon | SIEMENS BIT II | 1 | 61126907881 | Entfallen | Shop at ECS Tuning | ||||
| Für Fahrzeuge mit Bordmonitor mit TV und Navigationssystem Professional und Spracheingabe |
S602A=Ja S609A=Nein S620A=Ja |
|||||||||
| 01 | Verbindungskabel Autotelefon | SIEMENS BIT II | 1 | 61126907882 | Entfallen | Shop at ECS Tuning | ||||
| Für Fahrzeuge mit Bordmonitor mit TV und Navigationssystem Professional und Spracheingabe |
S602A=Nein S609A=Ja S620A=Ja |
|||||||||
| 01 | Verbindungskabel Autotelefon | SIEMENS BIT II | 1 | 61126907882 | Entfallen | Shop at ECS Tuning | ||||
| 02 | Sende-Empfangsgerät | SIEMENS BIT II | 1 | 12/2001 | 84116916766 | Entfallen | Shop at ECS Tuning | |||
| 02 | Sende-Empfangsger./Bedienhörer | SIEMENS BIT II | 1 | 12/2001 | 84116924824 | Entfallen | Shop at ECS Tuning | |||
| 02 | Sende-Empfangsgerät | SIEMENS BIT II | 1 | 12/2001 | 84116924823 | Shop at ECS Tuning | ||||
| nur in Verbindung mit | ||||||||||
| -- | Bedienhörer | SIEMENS BIT II | 1 | 12/2001 | 84116920275 | Entfallen | Shop at ECS Tuning | |||
| Für Fahrzeuge mit CD Laufwerk oder MD-Laufwerk |
S650A=Ja S651A=Ja |
|||||||||
| 02 | Sende-Empfangsgerät | SIEMENS BIT II | 1 | 09/2001 | 84116916766 | Entfallen | Shop at ECS Tuning | |||
| nur in Verbindung mit | ||||||||||
| 02 | Sende-Empfangsgerät | SIEMENS BIT II | 1 | 09/2001 | 84116924823 | Shop at ECS Tuning | ||||
| nur in Verbindung mit | ||||||||||
| -- | Adapter | 1 | 09/2001 | 61126916759 | $42.41 | Entfallen | Shop at ECS Tuning | |||
| 03 | Halter Sende-Empfangsgerät | SIEMENS BIT II | 1 | 84136908460 | Entfallen | Shop at ECS Tuning | ||||
| 04 | Sechskantschraube | M5X14 | 4 | 07119902932 | $0.53 | Shop at ECS Tuning | ||||
| 05 | Blechmutter | M5 | 4 | 61131372033 | $1.37 | Shop at ECS Tuning | ||||
| 06 | Sechskantmutter mit Scheibe | M5 | 2 | 63259128043 | $0.72 | Shop at ECS Tuning | ||||
| 07 | Antenne | BLUETOOTH | 1 | 84506928461 | $24.30 | +Pfand | Shop at ECS Tuning | |||
| 08 | Halter Basisantenne | 1 | 84136908814 | Shop at ECS Tuning | ||||||
| 09 | Hutmutter | M5 | 2 | 51711934930 | $0.23 | Shop at ECS Tuning | ||||
| 10 | Sechskantmutter | AM5-8-ZNS3 | 2 | 07129902975 | $0.36 | Shop at ECS Tuning | ||||
| 11 | Dichtstreifen | 1 | 51411970578 | $0.22 | Shop at ECS Tuning | |||||
| 12 | Rep.-Satz Buchsengehäuse | 54 POL. | 1 | 61132471244 | Shop at ECS Tuning | |||||
| nur in Verbindung mit | ||||||||||
| -- | Buchsengehäuse | 37-54POL. | 1 | 61136909070 | $1.08 | Shop at ECS Tuning | ||||
| -- | Buchsengehäuse | 36 POL. | 1 | 61136920062 | $1.22 | Shop at ECS Tuning | ||||
| -- | Buchsenkontakt MQS | 0.2-0.5MM²/SN | 54 | 61138369696 | $0.28 | Shop at ECS Tuning | ||||
| -- | Buchsenkontakt MQS | 0.75 MM² /SN | 54 | 61138369700 | $0.35 | Shop at ECS Tuning | ||||
Ergänzungen
- Entfallen = nicht mehr lieferbar.
- +Pfand = plus Altteilepfand (Möglicherweise muss das Altteil im Austausch abgegeben werden)
