Einzelteile SA 638 Gepäckraum for BMW 5 Series E39 523i (2000)
This Einzelteile SA 638 Gepäckraum technical drawing provides a detailed breakdown of the assembly for the 5 Series E39 523i. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2000.
| Nr. | Beschreibung | Erläuterungen | Anzahl | Von | Bis | Teilenummer | Preis | Ergänzungen | ||
|---|---|---|---|---|---|---|---|---|---|---|
| PuMA Massnahme 53476121 beachten | ||||||||||
| 01 | Telematics Control Unit | GSM | 1 | 84106978533 | Entfallen | Shop at ECS Tuning | ||||
| 01 | RP REMAN Telematics Control Unit | GSM | 1 | 84109187926 | Shop at ECS Tuning | |||||
| 02 | Sechskantmutter mit Scheibe | M5 | 5 | 63259128043 | $0.72 | Shop at ECS Tuning | ||||
| Für Fahrzeuge mit Navigationssystem Professional oder CD-Wechsler 6-fach oder HiFi Lautsprechersystem oder HiFi System Professional DSP oder Vorbereitung BMW 6 CD Wechsler oder Individual Audiosystem |
S609A=Ja S672A=Ja S676A=Ja S677A=Ja S694A=Ja S752A=Ja |
|||||||||
| 03 | Halter Telematics Control Unit | 1 | 84136924547 | $32.89 | +Pfand | Shop at ECS Tuning | ||||
| 04 | Sechskantschraube | M5X14 | 2 | 07119902932 | $0.53 | Shop at ECS Tuning | ||||
| 05 | Blechmutter | M5 | 2 | 61131372033 | $1.37 | Shop at ECS Tuning | ||||
| 06 | Halter Basisantenne | 1 | 84136908814 | Shop at ECS Tuning | ||||||
| 07 | Antenne | BLUETOOTH | 1 | 84506928461 | $24.30 | +Pfand | Shop at ECS Tuning | |||
| 08 | Sechskantmutter | AM5-8-ZNS3 | 2 | 07129902975 | $0.36 | Shop at ECS Tuning | ||||
| 09 | Hutmutter | M5 | 2 | 51711934930 | $0.23 | Shop at ECS Tuning | ||||
| 10 | Satz Filzstreifen selbstklebend | 1 | 07/2003 | 51452353024 | Shop at ECS Tuning | |||||
| 11 | Halter Telematics Control Unit | 1 | 84136924546 | $23.96 | +Pfand | Shop at ECS Tuning | ||||
| 12 | Spreizmutter | 2 | 63131378066 | $0.23 | Shop at ECS Tuning | |||||
Ergänzungen
- Entfallen = nicht mehr lieferbar.
- +Pfand = plus Altteilepfand (Möglicherweise muss das Altteil im Austausch abgegeben werden)
