Δοχείο λαδιού υδρ.συστ.διεύθ.επιμ.εξαρτ. for BMW 2.5CS-3.0CSL 3.0CSL (1973)
This Δοχείο λαδιού υδρ.συστ.διεύθ.επιμ.εξαρτ. technical drawing provides a detailed breakdown of the assembly for the 2.5CS-3.0CSL 3.0CSL. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1973.
| Αρ. | Περιγραφή | Συμπλ. Στοιχεία | Ποσότητα | Από | Έως | Αρ. Ανταλλακτικού | Τιμή | Σημειώσεις | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Ροδέλα αποστάτης | 2,250MM | 1 | 32131104856 | ΛΗΞΗ | Shop at ECS Tuning | ||||
| 01 | Ροδέλα αποστάτης | 2,300MM | 1 | 32131104858 | ΛΗΞΗ | Shop at ECS Tuning | ||||
| 01 | Ροδέλα αποστάτης | 2,350MM | 1 | 32131104860 | ΛΗΞΗ | Shop at ECS Tuning | ||||
| 01 | Ροδέλα αποστάτης | 2,400MM | 1 | 32131104862 | ΛΗΞΗ | Shop at ECS Tuning | ||||
| 01 | Ροδέλα αποστάτης | 2,260MM | 1 | 32131109238 | ΛΗΞΗ | Shop at ECS Tuning | ||||
| 01 | Ροδέλα αποστάτης | 2,270MM | 1 | 32131109239 | ΛΗΞΗ | Shop at ECS Tuning | ||||
| 01 | Ροδέλα αποστάτης | 2,280MM | 1 | 32131109240 | ΛΗΞΗ | Shop at ECS Tuning | ||||
| 01 | Ροδέλα αποστάτης | 2,290MM | 1 | 32131109241 | ΛΗΞΗ | Shop at ECS Tuning | ||||
| 01 | Ροδέλα αποστάτης | 2,310MM | 1 | 32131109242 | ΛΗΞΗ | Shop at ECS Tuning | ||||
| 01 | Ροδέλα αποστάτης | 2,320MM | 1 | 32131109243 | ΛΗΞΗ | Shop at ECS Tuning | ||||
| 01 | Ροδέλα αποστάτης | 2,330MM | 1 | 32131109244 | ΛΗΞΗ | Shop at ECS Tuning | ||||
| 01 | Ροδέλα αποστάτης | 2,340MM | 1 | 32131109245 | ΛΗΞΗ | Shop at ECS Tuning | ||||
| 01 | Ροδέλα αποστάτης | 2,360MM | 1 | 32131109246 | ΛΗΞΗ | Shop at ECS Tuning | ||||
| 01 | Ροδέλα αποστάτης | 2,370MM | 1 | 32131109247 | ΛΗΞΗ | Shop at ECS Tuning | ||||
| 01 | Ροδέλα αποστάτης | 2,380MM | 1 | 32131109248 | ΛΗΞΗ | Shop at ECS Tuning | ||||
| 01 | Ροδέλα αποστάτης | 2,390MM | 1 | 32131109249 | ΛΗΞΗ | Shop at ECS Tuning |
Σημειώσεις
- ΛΗΞΗ = Το ανταλλακτικό έχει διακοπεί.
See Also
Frequently Asked Questions
- What assembly is shown in the BMW 2.5CS-3.0CSL 3.0CSL Δοχείο λαδιού υδρ.συστ.διεύθ.επιμ.εξαρτ.?
- This technical diagram illustrates the Δοχείο λαδιού υδρ.συστ.διεύθ.επιμ.εξαρτ. within the Μηχανισμός διεύθυνσης group for the 2.5CS-3.0CSL 3.0CSL produced during 1973. It provides a detailed exploded view of the components, identifying key parts such as the Ροδέλα αποστάτης (Part #32131104856).
- Which models use the hardware listed in this Δοχείο λαδιού υδρ.συστ.διεύθ.επιμ.εξαρτ.?
- The hardware and components featured in the Δοχείο λαδιού υδρ.συστ.διεύθ.επιμ.εξαρτ. are specific to the 2.5CS-3.0CSL 3.0CSL produced during 1973. These technical specifications ensure that parts like the Ροδέλα αποστάτης (32131104856) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Δοχείο λαδιού υδρ.συστ.διεύθ.επιμ.εξαρτ. assembly?
- Each item in the Δοχείο λαδιού υδρ.συστ.διεύθ.επιμ.εξαρτ. corresponds to the numbered list below the illustration. For the 2.5CS-3.0CSL 3.0CSL, you can identify the Ροδέλα αποστάτης by locating its position on the schematic, which then links to the official BMW part number 32131104856 for the Μηχανισμός διεύθυνσης section.
