Rear seat ski bag for BMW 5 Series E60 540i (2005)
This Rear seat ski bag technical drawing provides a detailed breakdown of the assembly for the 5 Series E60 540i. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2005.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| For vehicles with Leather "Dakota"/kastanienbraun |
LCRK=Yes |
|||||||||
| 01 | Ski bag | ROTORANGE | 1 | 52207169521 | $370.88 | ENDED | Shop at ECS Tuning | |||
| For vehicles with Ski bag |
S464A=Yes |
|||||||||
| 01 | Ski bag | SCHWARZ | 1 | 52209146916 | $370.88 | ENDED | Shop at ECS Tuning | |||
| 01 | Ski bag | GRAU | 1 | 52209146917 | $361.22 | ENDED | Shop at ECS Tuning | |||
| 01 | Ski bag | BEIGE | 1 | 52209146918 | $361.22 | ENDED | Shop at ECS Tuning | |||
| 01 | Ski bag | CREAMBEIGE | 1 | 52209146970 | $370.88 | ENDED | Shop at ECS Tuning | |||
| 01 | Ski bag | DUNKELBLAU | 1 | 52209146971 | $370.88 | ENDED | Shop at ECS Tuning | |||
| 01 | Ski bag | NATURBRAUN | 1 | 52209146972 | $361.22 | ENDED | Shop at ECS Tuning | |||
| 01 | Ski bag | TABAK | 1 | 52209146973 | $361.22 | ENDED | Shop at ECS Tuning | |||
| For vehicles with Leather "Dakota"/amethyst or Leather fulled napa "Skin"/amethyst |
LCRH=Yes LDRH=Yes |
|||||||||
| 01 | Ski bag | AMETHYST | 1 | 52207160553 | $279.00 | ENDED | Shop at ECS Tuning | |||
| For vehicles with Fabr./leath."React/Oregon"/trüffel-braun or Leather "Dakota"/trüffel-braun |
FBTE=Yes LCTE=Yes |
|||||||||
| 01 | Ski bag | TRÜFFELBRAUN | 1 | 52207169522 | $370.88 | ENDED | Shop at ECS Tuning | |||
| For vehicles with Ski bag |
S464A=Yes |
|||||||||
| 02 | Frame ski bag | SCHWARZ | 1 | 52207160565 | $58.00 | Shop at ECS Tuning | ||||
| For vehicles with Leather "Dakota"/grau |
LCAD=Yes |
|||||||||
| 03 | Armrest panel | GRAU | 1 | 52207115865 | $81.38 | ENDED, +core | Shop at ECS Tuning | |||
| For vehicles with Ski bag |
S464A=Yes |
|||||||||
| 03 | Armrest panel | CREAMBEIGE | 1 | 52209128004 | $81.38 | ENDED | Shop at ECS Tuning | |||
| 03 | Armrest panel | DUNKELBLAU | 1 | 52209128005 | $81.38 | ENDED | Shop at ECS Tuning | |||
| 03 | Armrest panel | NATURBRAUN | 1 | 52209128006 | $81.38 | ENDED | Shop at ECS Tuning | |||
| 03 | Armrest panel | TABAK | 1 | 52209128007 | $81.38 | ENDED | Shop at ECS Tuning | |||
| For vehicles with Fabr./leath."React/Oregon"/trüffel-braun or Leather "Dakota"/trüffel-braun |
FBTE=Yes LCTE=Yes |
|||||||||
| 03 | Armrest panel | AMETHYST | 1 | 52207132465 | $66.96 | ENDED, +core | Shop at ECS Tuning | |||
| For vehicles with Imitation leather, beige or Leather "Dakota"/beige or Leather "Nasca"/beige |
KBBA=Yes LCBA=Yes U6BA=Yes |
|||||||||
| 03 | Armrest panel | BEIGE | 1 | 52207115891 | $81.38 | ENDED | Shop at ECS Tuning | |||
| For vehicles with Fabric/leather "React/Oregon"/anthrazit or Cloth/leather flashlight/anthracite or Imitation leather/black or Leather "Dakota"/schwarz or Leather fulled napa "Skin"/schwarz or Leather "Nasca"/black |
FBAT=Yes GAAT=Yes KBSW=Yes LCSW=Yes LDSW=Yes U6SW=Yes |
|||||||||
| 03 | Armrest panel | SCHWARZ | 1 | 52207115864 | $81.38 | Shop at ECS Tuning | ||||
| For vehicles with Ski bag and Through-loading system |
S464A=No S465A=No |
|||||||||
| 04 | Armrest panel | SCHWARZ | 1 | 52207068104 | $46.75 | ENDED | Shop at ECS Tuning | |||
| 04 | Armrest panel | GRAU | 1 | 52207077379 | $46.75 | ENDED, +core | Shop at ECS Tuning | |||
| 04 | Armrest panel | AMETHYST | 1 | 52207132463 | $39.90 | ENDED, +core | Shop at ECS Tuning | |||
| 04 | Armrest panel | CREAMBEIGE | 1 | 52209128000 | ENDED, NoS | Shop at ECS Tuning | ||||
| 04 | Armrest panel | DUNKELBLAU | 1 | 52209128001 | ENDED, NoS | Shop at ECS Tuning | ||||
| 04 | Armrest panel | NATURBRAUN | 1 | 52209128002 | ENDED, NoS | Shop at ECS Tuning | ||||
| For vehicles with Imitation leather, beige or Leather "Dakota"/beige or Leather "Nasca"/beige |
KBBA=Yes LCBA=Yes U6BA=Yes |
|||||||||
| 04 | Armrest panel | BEIGE | 1 | 52207077340 | $46.75 | ENDED, +core | Shop at ECS Tuning | |||
| 05 | Torx bolt | ISA M6X20 | 4 | 51217069230 | $0.50 | Shop at ECS Tuning | ||||
Notes
- ENDED = the part has been discontinued (no longer available).
- +core = plus core charge (possibility of a return of the old part)
- NoS = No Stock (Part centrally not stocked)
