Sample chart with interior moldings for BMW 3 Series E90 M3 (2008)
This Sample chart with interior moldings technical drawing provides a detailed breakdown of the assembly for the 3 Series E90 M3. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2008.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| For vehicles with Interior trim strip in Titan Shadow |
S771A=Yes |
|||||||||
| 01 | Color names for this model: | X | 09/2013 | 51138888888 | Shop at ECS Tuning | |||||
| = Titan shadow | ||||||||||
| For vehicles with Int.trim,leather,carbon struct.,black |
S4MYA=Yes |
|||||||||
| 02 | Color names for this model: | X | 09/2013 | 51138888888 | Shop at ECS Tuning | |||||
| = Leder Carbonstruktur schwarz | ||||||||||
| For vehicles with Int. strips, Alu Shadow, linear polished |
S4MXA=Yes |
|||||||||
| 03 | Color names for this model: | X | 09/2013 | 51138888888 | Shop at ECS Tuning | |||||
| = Aluminium shadow Längsschliff | ||||||||||
| For vehicles with Fine wood sycamore mirror gr. anthracite |
S4MZA=Yes |
|||||||||
| 04 | Color names for this model: | X | 09/2013 | 51138888888 | Shop at ECS Tuning | |||||
| = Platane Spiegelmaser anthrazit | ||||||||||
