Sample chart, upholstery colors, leather for BMW 5 Series E61 525i (2005)
This Sample chart, upholstery colors, leather technical drawing provides a detailed breakdown of the assembly for the 5 Series E61 525i. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2005.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| For vehicles with Leather "Dakota"/trüffel-braun |
LCTE=Yes |
|||||||||
| 01 | Color names for this model: | X | 09/2002 | 09/2006 | 51138888888 | Shop at ECS Tuning | ||||
| = Trüffelbraun | ||||||||||
| For vehicles with Leather "Dakota"/amethyst |
LCRH=Yes |
|||||||||
| 02 | Color names for this model: | X | 09/2002 | 09/2006 | 51138888888 | Shop at ECS Tuning | ||||
| = Amethyst | ||||||||||
| For vehicles with Leather "Dakota"/kastanienbraun |
LCRK=Yes |
|||||||||
| 03 | Color names for this model: | X | 09/2002 | 09/2006 | 51138888888 | Shop at ECS Tuning | ||||
| = Kastanienbraun = Rotorange |
||||||||||
| For vehicles with Leather filled napa "Skin"/schwarz |
LDSW=Yes |
|||||||||
| 04 | Color names for this model: | X | 09/2002 | 09/2006 | 51138888888 | Shop at ECS Tuning | ||||
| = Black | ||||||||||
| For vehicles with Leather filled napa "Skin"/amethyst |
LDRH=Yes |
|||||||||
| 05 | Color names for this model: | X | 09/2002 | 09/2006 | 51138888888 | Shop at ECS Tuning | ||||
| = Amethyst | ||||||||||
