Sample page, upholstery colors, fabric for BMW 5 Series F07 GT 535dX (2012)
This Sample page, upholstery colors, fabric technical drawing provides a detailed breakdown of the assembly for the 5 Series F07 GT 535dX. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2012.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| For vehicles with Fabric "Diagonal/anthracite" |
AWAT=Yes |
|||||||||
| 01 | Color names for this model: | X | 09/2009 | 09/2013 | 51138888888 | Shop at ECS Tuning | ||||
| = Anthrazit | ||||||||||
| For vehicles with Fabric/leather Layer/Dakota/elfenbein-w. |
FNEW=Yes |
|||||||||
| 02 | Color names for this model: | X | 09/2009 | 09/2013 | 51138888888 | Shop at ECS Tuning | ||||
| = Elfenbeinweiss | ||||||||||
| For vehicles with Fabric/leather "Layer/Dakota/anthracite" |
FNAT=Yes |
|||||||||
| 03 | Color names for this model: | X | 09/2009 | 09/2013 | 51138888888 | Shop at ECS Tuning | ||||
| = Anthrazit | ||||||||||
| For vehicles with Fabric 'Gray Shadow/anthracite' |
AZAT=Yes |
|||||||||
| 04 | Color names for this model: | X | 09/2011 | 09/2013 | 51138888888 | Shop at ECS Tuning | ||||
| = Anthrazit/Schwarz | ||||||||||
