Quick Ref. Guide F20, F21 with iDrive for BMW 1 Series F20 LCI M140i (2019)
This Quick Ref. Guide F20, F21 with iDrive technical drawing provides a detailed breakdown of the assembly for the 1 Series F20 LCI M140i. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2019.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| i | Remaining brief instruction manuals for vehicles with SOP from 07/2014 only remain available in the following languages: - German (de) - English (en) - Chinese (zh) - English-US (enUS) - French-CDN (frCA) For vehicles with Navigation system Business or Navigation system Professional or Radio BMW Professional |
S606A=Yes S609A=Yes S663A=Yes |
||||||||
| For vehicles with CIC-Zusteuerung or Control for Infotainment |
S6VAA=Yes S6VBA=Yes |
|||||||||
| 01 | Quick Ref. Guide F20/F21 with iDrive | DE | 1 | 03/2014 | 01402925526 | Shop at ECS Tuning | ||||
| 02 | Quick Ref. Guide F20/F21 with iDrive | EN | 1 | 03/2014 | 01402925527 | Shop at ECS Tuning | ||||
| 03 | Quick Ref. Guide F20/F21 with iDrive | FR | 1 | 03/2014 | 01402925528 | Shop at ECS Tuning | ||||
| 04 | Quick Ref. Guide F20/F21 with iDrive | ES | 1 | 03/2014 | 01402925529 | ENDED | Shop at ECS Tuning | |||
| 05 | Quick Ref. Guide F20/F21 with iDrive | IT | 1 | 03/2014 | 01402925530 | ENDED | Shop at ECS Tuning | |||
| 06 | Quick Ref. Guide F20/F21 with iDrive | SV | 1 | 03/2014 | 01402925531 | ENDED | Shop at ECS Tuning | |||
| 07 | Quick Ref. Guide F20/F21 with iDrive | NL | 1 | 03/2014 | 01402925532 | Shop at ECS Tuning | ||||
| 08 | Quick Ref. Guide F20/F21 with iDrive | AR | 1 | 03/2014 | 01402925533 | ENDED | Shop at ECS Tuning | |||
| 09 | Quick Ref. Guide F20/F21 with iDrive | DA | 1 | 03/2014 | 01402925534 | ENDED | Shop at ECS Tuning | |||
| 10 | Quick Ref. Guide F20/F21 with iDrive | PT | 1 | 03/2014 | 01402925535 | ENDED | Shop at ECS Tuning | |||
| 11 | Quick Ref. Guide F20/F21 with iDrive | EL | 1 | 03/2014 | 01402925537 | ENDED | Shop at ECS Tuning | |||
| 12 | Quick Ref. Guide F20/F21 with iDrive | ZH | 1 | 03/2014 | 01402925536 | Shop at ECS Tuning | ||||
| 13 | Quick Ref. Guide F20/F21 with iDrive | KO | 1 | 03/2014 | 01402925538 | ENDED | Shop at ECS Tuning | |||
| 14 | Quick Ref. Guide F20/F21 with iDrive | RO | 1 | 03/2014 | 01402925540 | ENDED | Shop at ECS Tuning | |||
| 15 | Quick Ref. Guide F20/F21 with iDrive | RU | 1 | 03/2014 | 01402925539 | ENDED | Shop at ECS Tuning | |||
| 16 | Quick Ref. Guide F20/F21 with iDrive | JA | 1 | 03/2014 | 01402925541 | Shop at ECS Tuning | ||||
| 17 | Quick Ref. Guide F20/F21 with iDrive | ZHTW | 1 | 03/2014 | 01402925542 | Shop at ECS Tuning | ||||
| 18 | Quick Ref. Guide F20/F21 with iDrive | SK | 1 | 03/2014 | 01402925543 | ENDED | Shop at ECS Tuning | |||
| 19 | Quick Ref. Guide F20/F21 with iDrive | CS | 1 | 03/2014 | 01402925544 | ENDED | Shop at ECS Tuning | |||
| 21 | Quick Ref. Guide F20/F21 with iDrive | PL | 1 | 03/2014 | 01402925546 | ENDED | Shop at ECS Tuning | |||
| 22 | Quick Ref. Guide F20/F21 with iDrive | HU | 1 | 03/2014 | 01402925547 | ENDED | Shop at ECS Tuning | |||
| 23 | Quick Ref. Guide F20/F21 with iDrive | SL | 1 | 03/2014 | 01402925548 | ENDED | Shop at ECS Tuning | |||
Notes
- ENDED = the part has been discontinued (no longer available).
