Retrofit, outside mirror, electrochrome for BMW 7 Series E38 740i (1996)
This Retrofit, outside mirror, electrochrome technical drawing provides a detailed breakdown of the assembly for the 7 Series E38 740i. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1996.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 02 | Rearview mirror EC | 1 | 10/1997 | 51168174089 | $260.83 | ENDED | Shop at ECS Tuning | |||
| 02 | Rearview mirror EC | 1 | 10/1997 | 51168238066 | $224.95 | ENDED | Shop at ECS Tuning | |||
| only in conjunction with | ||||||||||
| 02 | Rearview mirror EC | 1 | 10/1997 | 51169134461 | $224.95 | ENDED | Shop at ECS Tuning | |||
| only in conjunction with | ||||||||||
| 02 | Rearview mirror EC / LED | 1 | 10/1997 | 51169134459 | $250.95 | Shop at ECS Tuning | ||||
| only in conjunction with | ||||||||||
| -- | Set of covers mirror baseplate | BLACK | 1 | 10/1997 | 51167062264 | $3.94 | Shop at ECS Tuning | |||
| 03 | Int. mirror wiring loom + auto. dip | 1 | 61129404614 | ENDED | Shop at ECS Tuning | |||||
Notes
- ENDED = the part has been discontinued (no longer available).
See Also
Frequently Asked Questions
- What assembly is shown in the BMW 7 Series E38 740i Retrofit, outside mirror, electrochrome?
- This technical diagram illustrates the Retrofit, outside mirror, electrochrome within the Retrofitting / conversion / accessories group for the 7 Series E38 740i produced during 1996. It provides a detailed exploded view of the components, identifying key parts such as the Rearview mirror EC (Part #51168174089).
- Which models use the hardware listed in this Retrofit, outside mirror, electrochrome?
- The hardware and components featured in the Retrofit, outside mirror, electrochrome are specific to the 7 Series E38 740i produced during 1996. These technical specifications ensure that parts like the Rearview mirror EC (51168174089) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Retrofit, outside mirror, electrochrome assembly?
- Each item in the Retrofit, outside mirror, electrochrome corresponds to the numbered list below the illustration. For the 7 Series E38 740i, you can identify the Rearview mirror EC by locating its position on the schematic, which then links to the official BMW part number 51168174089 for the Retrofitting / conversion / accessories section.
