Retrofit, outside mirror, electrochrome for BMW 3 Series E46 328i (2000)
This Retrofit, outside mirror, electrochrome technical drawing provides a detailed breakdown of the assembly for the 3 Series E46 328i. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2000.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| i | Installation time approx. 2.0 hours, which may vary depending on the condition of the vehicle and the equipment in it. |
|||||||||
| 01 | Rearview mirror EC / LED | 1 | 09/1998 | 51169134459 | $250.95 | Shop at ECS Tuning | ||||
| only in conjunction with | ||||||||||
| -- | Set of covers mirror baseplate | 1 | 09/1998 | 51167133655 | $13.17 | Shop at ECS Tuning | ||||
| additionally required parts: | ||||||||||
| For vehicles with Alarm system |
S302A=Yes |
|||||||||
| 01 | Rearview mirror EC / LED | 1 | 51169134459 | $250.95 | Shop at ECS Tuning | |||||
| only in conjunction with | ||||||||||
| -- | Set of covers mirror baseplate | 1 | 51167133655 | $13.17 | Shop at ECS Tuning | |||||
| additionally required parts: | ||||||||||
| 01 | Rearview mirror EC / LED / IR | INFRARED | 1 | 09/1998 | 51169134471 | $445.95 | Shop at ECS Tuning | |||
| additionally required parts: | ||||||||||
| 02 | Int. mirror wiring loom + auto. dip | 1 | 51160001231 | $26.25 | ENDED | Shop at ECS Tuning | ||||
Notes
- ENDED = the part has been discontinued (no longer available).
