Rubber mat for BMW 1 Series E87 LCI 118d (2011)
This Rubber mat technical drawing provides a detailed breakdown of the assembly for the 1 Series E87 LCI 118d. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2011.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| i | For vehicles with National version China |
L8AAA=No |
||||||||
| 03 | Hook&loop element with screw thread | D 50MM | 2 | 07147151866 | $8.49 | ENDED | Shop at ECS Tuning | |||
Notes
- ENDED = the part has been discontinued (no longer available).
See Also
Frequently Asked Questions
- What assembly is shown in the BMW 1 Series E87 LCI 118d Rubber mat?
- This technical diagram illustrates the Rubber mat within the Retrofitting / conversion / accessories group for the 1 Series E87 LCI 118d produced during 2011. It provides a detailed exploded view of the components, identifying key parts such as the Hook&loop element with screw thread (Part #07147151866).
- Which models use the hardware listed in this Rubber mat?
- The hardware and components featured in the Rubber mat are specific to the 1 Series E87 LCI 118d produced during 2011. These technical specifications ensure that parts like the Hook&loop element with screw thread (07147151866) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Rubber mat assembly?
- Each item in the Rubber mat corresponds to the numbered list below the illustration. For the 1 Series E87 LCI 118d, you can identify the Hook&loop element with screw thread by locating its position on the schematic, which then links to the official BMW part number 07147151866 for the Retrofitting / conversion / accessories section.
