Aerodynamics package for BMW 5 Series E34 525td (1995)
This Aerodynamics package technical drawing provides a detailed breakdown of the assembly for the 5 Series E34 525td. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1995.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| i | Important notice: The installation instructions are not included in the retrofit kit. Print out the latest update of the instructions from the Aftersales Assistance Portal (ASAP) and hand them over to the customer. |
|||||||||
| 01 | Installing set spoiler front | GRUNDIERT | 1 | 82119401181 | $312.95 | ENDED, ABE 9785090 | Shop at ECS Tuning | |||
| 03 | Flap, towing eye | ERSATZTEIL | 1 | 82119401197 | ENDED | Shop at ECS Tuning | ||||
| For vehicles with Trailer coupling or Park Distance Control |
=No =No |
|||||||||
| 03 | Installing set rear apron | GRUNDIERT | 1 | 82119401182 | ENDED, ABE 9785093 | Shop at ECS Tuning | ||||
| 05 | Flap, towing eye | ERSATZTEIL | 1 | 82119401196 | $22.88 | Shop at ECS Tuning | ||||
Notes
- ENDED = the part has been discontinued (no longer available).
- ABE = Allgemeine Betriebserlaubnis (General Operating Permit)
