Retrofit universal remote control for BMW 7 Series F01 750iX (2012)
This Retrofit universal remote control technical drawing provides a detailed breakdown of the assembly for the 7 Series F01 750iX. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2012.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| i | For this retrofit there are no installation instructions. To be installed by skilled personnel only, best by a BMW partner. BMW is unable to accept any responsibility for operating failures and damages resulting from incorrect installation. Installation time approx. 0.5 hours, which may vary depending on the condition of the vehicle and the equipment in it. For vehicles with Interior/outside mirror with auto dip or Interior mirror with automatic-dip |
S430A=Yes S431A=Yes |
||||||||
| For vehicles with High-beam assistant or Lane departure warning Observe instructions in Repair Manual REP -51 16 063! |
S5ACA=No S5ADA=Yes |
|||||||||
| 01 | Rearview mirror EC / LED / GTO | 1 | 51169224345 | Shop at ECS Tuning | ||||||
| For vehicles with High-beam assistant and Lane departure warning Observe instructions in Repair Manual REP -51 16 063! |
S5ACA=Yes S5ADA=No |
|||||||||
| 02 | Rearview mirror EC / LED / GTO / FLA | 1 | 51169228258 | Shop at ECS Tuning | ||||||
