Retrofit kit M aerodyn. package for BMW 1 Series E81 120i (2011)
This Retrofit kit M aerodyn. package technical drawing provides a detailed breakdown of the assembly for the 1 Series E81 120i. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2011.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| i | The retrofit kits do not contain rocker panel trim panels. For vehicles without fog headlights it is necessary to refit wiring and the switch fog headlights are not included in kit The front bumper bracket must be replaced, refer to ITU 51_5402 Important notice: The installation instructions are not included in the retrofit kit. Print out the latest update of the instructions from the Aftersales Assistance Portal (ASAP) and hand them over to the customer. |
|||||||||
| 01 | Retrofit kit M aerodyn. package | GRUNDIERT | 1 | 51950422316 | ENDED | Shop at ECS Tuning | ||||
| only in conjunction with | ||||||||||
| -- | Fog lights, left | 1 | 63176924655 | $125.48 | Shop at ECS Tuning | |||||
| -- | Fog lights, right | 1 | 63176924656 | $125.48 | Shop at ECS Tuning | |||||
| -- | Horn, low pitch | 1 | 61337192038 | $42.63 | +core | Shop at ECS Tuning | ||||
| -- | Horn, high pitch | 1 | 61337192039 | $41.63 | +core | Shop at ECS Tuning | ||||
| -- | Retrofit kit, M door sill trim, primed | GRUNDIERT | 1 | 51950435802 | ENDED | Shop at ECS Tuning | ||||
| -- | Supporting ledge left | 1 | 51777118159 | $2.65 | Shop at ECS Tuning | |||||
| -- | Supporting ledge right | 1 | 51777118160 | $2.65 | Shop at ECS Tuning | |||||
| -- | Front left brake air duct | 1 | 51747906805 | Shop at ECS Tuning | ||||||
| -- | Front right brake air duct | 1 | 51747906806 | Shop at ECS Tuning | ||||||
| -- | Protective adhesive film | 40X40MM | 1 | 51718102827 | $0.63 | Shop at ECS Tuning | ||||
| -- | Intermediate part air duct center bottom | 1 | 51647836650 | Shop at ECS Tuning | ||||||
| -- | Expanding nut | 6 | 51327000058 | $0.39 | Shop at ECS Tuning | |||||
| -- | Trim panel, bumper, rear, bottom | SCHIEFERGRAU | 1 | 51127837325 | +core | Shop at ECS Tuning | ||||
| -- | Carrier, bumper front | 1 | 51117058450 | Shop at ECS Tuning | ||||||
| -- | Protective adhesive film | 90X60MM | 1 | 07148045544 | $3.38 | Shop at ECS Tuning | ||||
| -- | Hex head screw | ST4,8X13-C-U1-Z | 6 | 07119906128 | $0.18 | Shop at ECS Tuning | ||||
| For vehicles with Headlight cleaning system |
S502A=Yes |
|||||||||
| 01 | Retrofit kit M aerodyn. package | GRUNDIERT | 1 | 51950422319 | ENDED | Shop at ECS Tuning | ||||
| only in conjunction with | ||||||||||
| -- | Fog lights, left | 1 | 63176924655 | $125.48 | Shop at ECS Tuning | |||||
| -- | Fog lights, right | 1 | 63176924656 | $125.48 | Shop at ECS Tuning | |||||
| -- | Horn, low pitch | 1 | 61337192038 | $42.63 | +core | Shop at ECS Tuning | ||||
| -- | Horn, high pitch | 1 | 61337192039 | $41.63 | +core | Shop at ECS Tuning | ||||
| -- | Cable tie | L=200MM/B=3,6MM | 10 | 61131367599 | $0.43 | Shop at ECS Tuning | ||||
| -- | Retrofit kit, M door sill trim, primed | GRUNDIERT | 1 | 51950435802 | ENDED | Shop at ECS Tuning | ||||
| -- | Supporting ledge left | 1 | 51777118159 | $2.65 | Shop at ECS Tuning | |||||
| -- | Supporting ledge right | 1 | 51777118160 | $2.65 | Shop at ECS Tuning | |||||
| -- | Front left brake air duct | 1 | 51747906805 | Shop at ECS Tuning | ||||||
| -- | Front right brake air duct | 1 | 51747906806 | Shop at ECS Tuning | ||||||
| -- | Protective adhesive film | 40X40MM | 1 | 51718102827 | $0.63 | Shop at ECS Tuning | ||||
| -- | Intermediate part air duct center bottom | 1 | 51647836650 | Shop at ECS Tuning | ||||||
| -- | Expanding nut | 1 | 51327000058 | $0.39 | Shop at ECS Tuning | |||||
| -- | Trim panel, bumper, rear, bottom | SCHIEFERGRAU | 1 | 51127837325 | +core | Shop at ECS Tuning | ||||
| -- | Carrier, bumper front | 1 | 51117058450 | Shop at ECS Tuning | ||||||
| -- | Protective adhesive film | 90X60MM | 1 | 07148045544 | $3.38 | Shop at ECS Tuning | ||||
| -- | Hex head screw | ST4,8X13-C-U1-Z | 1 | 07119906128 | $0.18 | Shop at ECS Tuning | ||||
| For vehicles with Park Distance Control (PDC) |
S508A=Yes |
|||||||||
| 01 | Retrofit kit M aerodyn. package | GRUNDIERT | 1 | 51950422318 | ENDED | Shop at ECS Tuning | ||||
| only in conjunction with | ||||||||||
| -- | Fog lights, left | 1 | 63176924655 | $125.48 | Shop at ECS Tuning | |||||
| -- | Fog lights, right | 1 | 63176924656 | $125.48 | Shop at ECS Tuning | |||||
| -- | Horn, low pitch | 1 | 61337192038 | $42.63 | +core | Shop at ECS Tuning | ||||
| -- | Horn, high pitch | 1 | 61337192039 | $41.63 | +core | Shop at ECS Tuning | ||||
| -- | Retrofit kit, M door sill trim, primed | GRUNDIERT | 1 | 51950435802 | ENDED | Shop at ECS Tuning | ||||
| -- | Supporting ledge left | 1 | 51777118159 | $2.65 | Shop at ECS Tuning | |||||
| -- | Supporting ledge right | 1 | 51777118160 | $2.65 | Shop at ECS Tuning | |||||
| -- | Front left brake air duct | 1 | 51747906805 | Shop at ECS Tuning | ||||||
| -- | Front right brake air duct | 1 | 51747906806 | Shop at ECS Tuning | ||||||
| -- | Protective adhesive film | 40X40MM | 1 | 51718102827 | $0.63 | Shop at ECS Tuning | ||||
| -- | Intermediate part air duct center bottom | 1 | 51647836650 | Shop at ECS Tuning | ||||||
| -- | Expanding nut | 6 | 51327000058 | $0.39 | Shop at ECS Tuning | |||||
| -- | Trim panel, bumper, rear, bottom | SCHIEFERGRAU | 1 | 51127837325 | +core | Shop at ECS Tuning | ||||
| -- | Carrier, bumper front | 1 | 51117058450 | Shop at ECS Tuning | ||||||
| -- | Protective adhesive film | 90X60MM | 1 | 07148045544 | $3.38 | Shop at ECS Tuning | ||||
| -- | Hex head screw | ST4,8X13-C-U1-Z | 6 | 07119906128 | $0.18 | Shop at ECS Tuning | ||||
| For vehicles with Park Distance Control (PDC), rear |
S507A=Yes |
|||||||||
| 01 | Retrofit kit M aerodyn. package | GRUNDIERT | 1 | 51950422317 | ENDED | Shop at ECS Tuning | ||||
| only in conjunction with | ||||||||||
| -- | Fog lights, left | 1 | 63176924655 | $125.48 | Shop at ECS Tuning | |||||
| -- | Fog lights, right | 1 | 63176924656 | $125.48 | Shop at ECS Tuning | |||||
| -- | Horn, low pitch | 1 | 61337192038 | $42.63 | +core | Shop at ECS Tuning | ||||
| -- | Horn, high pitch | 1 | 61337192039 | $41.63 | +core | Shop at ECS Tuning | ||||
| -- | Retrofit kit, M door sill trim, primed | GRUNDIERT | 1 | 51950435802 | ENDED | Shop at ECS Tuning | ||||
| -- | Supporting ledge left | 1 | 51777118159 | $2.65 | Shop at ECS Tuning | |||||
| -- | Supporting ledge right | 1 | 51777118160 | $2.65 | Shop at ECS Tuning | |||||
| -- | Front left brake air duct | 1 | 51747906805 | Shop at ECS Tuning | ||||||
| -- | Front right brake air duct | 1 | 51747906806 | Shop at ECS Tuning | ||||||
| -- | Protective adhesive film | 40X40MM | 1 | 51718102827 | $0.63 | Shop at ECS Tuning | ||||
| -- | Intermediate part air duct center bottom | 1 | 51647836650 | Shop at ECS Tuning | ||||||
| -- | Expanding nut | 6 | 51327000058 | $0.39 | Shop at ECS Tuning | |||||
| -- | Trim panel, bumper, rear, bottom | SCHIEFERGRAU | 1 | 51127837325 | +core | Shop at ECS Tuning | ||||
| -- | Carrier, bumper front | 1 | 51117058450 | Shop at ECS Tuning | ||||||
| -- | Protective adhesive film | 90X60MM | 1 | 07148045544 | $3.38 | Shop at ECS Tuning | ||||
| -- | Hex head screw | ST4,8X13-C-U1-Z | 6 | 07119906128 | $0.18 | Shop at ECS Tuning | ||||
| For vehicles with Headlight cleaning system and Park Distance Control (PDC) |
S502A=Yes S508A=Yes |
|||||||||
| 01 | Retrofit kit M aerodyn. package | GRUNDIERT | 1 | 51950422321 | ENDED | Shop at ECS Tuning | ||||
| only in conjunction with | ||||||||||
| -- | Fog lights, left | 1 | 63176924655 | $125.48 | Shop at ECS Tuning | |||||
| -- | Fog lights, right | 1 | 63176924656 | $125.48 | Shop at ECS Tuning | |||||
| -- | Horn, low pitch | 1 | 61337192038 | $42.63 | +core | Shop at ECS Tuning | ||||
| -- | Horn, high pitch | 1 | 61337192039 | $41.63 | +core | Shop at ECS Tuning | ||||
| -- | Cable tie | L=200MM/B=3,6MM | 10 | 61131367599 | $0.43 | Shop at ECS Tuning | ||||
| -- | Retrofit kit, M door sill trim, primed | GRUNDIERT | 1 | 51950435802 | ENDED | Shop at ECS Tuning | ||||
| -- | Supporting ledge left | 1 | 51777118159 | $2.65 | Shop at ECS Tuning | |||||
| -- | Supporting ledge right | 1 | 51777118160 | $2.65 | Shop at ECS Tuning | |||||
| -- | Front left brake air duct | 1 | 51747906805 | Shop at ECS Tuning | ||||||
| -- | Front right brake air duct | 1 | 51747906806 | Shop at ECS Tuning | ||||||
| -- | Protective adhesive film | 40X40MM | 1 | 51718102827 | $0.63 | Shop at ECS Tuning | ||||
| -- | Intermediate part air duct center bottom | 1 | 51647836650 | Shop at ECS Tuning | ||||||
| -- | Expanding nut | 6 | 51327000058 | $0.39 | Shop at ECS Tuning | |||||
| -- | Trim panel, bumper, rear, bottom | SCHIEFERGRAU | 1 | 51127837325 | +core | Shop at ECS Tuning | ||||
| -- | Carrier, bumper front | 1 | 51117058450 | Shop at ECS Tuning | ||||||
| -- | Protective adhesive film | 90X60MM | 1 | 07148045544 | $3.38 | Shop at ECS Tuning | ||||
| -- | Hex head screw | ST4,8X13-C-U1-Z | 6 | 07119906128 | $0.18 | Shop at ECS Tuning | ||||
| For vehicles with Headlight cleaning system and Park Distance Control (PDC), rear |
S502A=Yes S507A=Yes |
|||||||||
| 01 | Retrofit kit M aerodyn. package | GRUNDIERT | 1 | 51950422320 | ENDED | Shop at ECS Tuning | ||||
| only in conjunction with | ||||||||||
| -- | Fog lights, left | 1 | 63176924655 | $125.48 | Shop at ECS Tuning | |||||
| -- | Fog lights, right | 1 | 63176924656 | $125.48 | Shop at ECS Tuning | |||||
| -- | Horn, low pitch | 1 | 61337192038 | $42.63 | +core | Shop at ECS Tuning | ||||
| -- | Horn, high pitch | 1 | 61337192039 | $41.63 | +core | Shop at ECS Tuning | ||||
| -- | Cable tie | L=200MM/B=3,6MM | 10 | 61131367599 | $0.43 | Shop at ECS Tuning | ||||
| -- | Retrofit kit, M door sill trim, primed | GRUNDIERT | 1 | 51950435802 | ENDED | Shop at ECS Tuning | ||||
| -- | Supporting ledge left | 1 | 51777118159 | $2.65 | Shop at ECS Tuning | |||||
| -- | Supporting ledge right | 1 | 51777118160 | $2.65 | Shop at ECS Tuning | |||||
| -- | Front left brake air duct | 1 | 51747906805 | Shop at ECS Tuning | ||||||
| -- | Front right brake air duct | 1 | 51747906806 | Shop at ECS Tuning | ||||||
| -- | Protective adhesive film | 40X40MM | 1 | 51718102827 | $0.63 | Shop at ECS Tuning | ||||
| -- | Intermediate part air duct center bottom | 1 | 51647836650 | Shop at ECS Tuning | ||||||
| -- | Expanding nut | 6 | 51327000058 | $0.39 | Shop at ECS Tuning | |||||
| -- | Trim panel, bumper, rear, bottom | SCHIEFERGRAU | 1 | 51127837325 | +core | Shop at ECS Tuning | ||||
| -- | Carrier, bumper front | 1 | 51117058450 | Shop at ECS Tuning | ||||||
| -- | Protective adhesive film | 90X60MM | 1 | 07148045544 | $3.38 | Shop at ECS Tuning | ||||
| -- | Hex head screw | ST4,8X13-C-U1-Z | 6 | 07119906128 | $0.18 | Shop at ECS Tuning | ||||
| For vehicles with Control of number-plate attachment |
S992A=Yes |
|||||||||
| 02 | Licence plate base | -M- | 1 | 51117906811 | +core | Shop at ECS Tuning | ||||
| 03 | Fillister head screw | TS5X20 | 4 | 07146986938 | $0.45 | Shop at ECS Tuning | ||||
| For vehicles with Towing hitch, detachable |
S235A=Yes |
|||||||||
| 04 | Cover for tow hitch, lower | 1 | 51127118162 | Shop at ECS Tuning | ||||||
Notes
- ENDED = the part has been discontinued (no longer available).
- +core = plus core charge (possibility of a return of the old part)
