Vent window, electric, rear for BMW 3 Series E36 325i (1995)
This Vent window, electric, rear technical drawing provides a detailed breakdown of the assembly for the 3 Series E36 325i. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1995.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| i | Important notice: The installation instructions are not included in the retrofit kit. Print out the latest update of the instructions from the Aftersales Assistance Portal (ASAP) and hand them over to the customer. |
|||||||||
| 01 | Retrofit kit, electric vent window, rear | 1 | 51369402689 | $316.95 | ENDED | Shop at ECS Tuning | ||||
| ONLY IN CONJUNCTION WITH WIRING SET ELECTR.VENT WINDO REAR |
||||||||||
| 02 | Wiring set electr.vent windo rear | 1 | 09/1993 | 61129402660 | $70.50 | ENDED | Shop at ECS Tuning | |||
| 03 | Wiring set for power supply | 1 | 09/1993 | 61129404366 | $23.50 | ENDED | Shop at ECS Tuning | |||
Notes
- ENDED = the part has been discontinued (no longer available).
