Retrofit snap-on drink holder for BMW 1 Series E87 LCI 123d (2011)
This Retrofit snap-on drink holder technical drawing provides a detailed breakdown of the assembly for the 1 Series E87 LCI 123d. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2011.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| i | For vehicles with Cup holder |
S442A=No |
||||||||
| 01 | Cup holder | 1 | 51160443082 | $30.75 | ENDED | Shop at ECS Tuning | ||||
| only in conjunction with item 3 | ||||||||||
| 02 | Front CAN holder | 1 | 51169122655 | $39.23 | Shop at ECS Tuning | |||||
| 03 | Cover, cup holder | SCHWARZ | 1 | 51169144632 | $23.17 | Shop at ECS Tuning | ||||
| 03 | Cover, cup holder | ALASKAGRAU | 1 | 51169144633 | $23.17 | Shop at ECS Tuning | ||||
| 03 | Cover, cup holder | BEIGE | 1 | 51169144634 | $23.17 | Shop at ECS Tuning | ||||
Notes
- ENDED = the part has been discontinued (no longer available).
See Also
Frequently Asked Questions
- What assembly is shown in the BMW 1 Series E87 LCI 123d Retrofit snap-on drink holder?
- This technical diagram illustrates the Retrofit snap-on drink holder within the Retrofitting / conversion / accessories group for the 1 Series E87 LCI 123d produced during 2011. It provides a detailed exploded view of the components, identifying key parts such as the Cup holder (Part #51160443082).
- Which models use the hardware listed in this Retrofit snap-on drink holder?
- The hardware and components featured in the Retrofit snap-on drink holder are specific to the 1 Series E87 LCI 123d produced during 2011. These technical specifications ensure that parts like the Cup holder (51160443082) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Retrofit snap-on drink holder assembly?
- Each item in the Retrofit snap-on drink holder corresponds to the numbered list below the illustration. For the 1 Series E87 LCI 123d, you can identify the Cup holder by locating its position on the schematic, which then links to the official BMW part number 51160443082 for the Retrofitting / conversion / accessories section.
