Ashtray rear for BMW 3 Series E90 320d (2007)
This Ashtray rear technical drawing provides a detailed breakdown of the assembly for the 3 Series E90 320d. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2007.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| For vehicles with Cloth "Fluid" or "Linea"/grey or Leather "Dakota"/grau |
ALAD=Yes LCAD=Yes |
|||||||||
| 01 | Covering rear | SCHWARZ | 1 | 51167145681 | $16.25 | Shop at ECS Tuning | ||||
| For vehicles with Cloth "Fluid"/beige or Sensatec/beige or Leather "Dakota"/beige |
ALB4=Yes KAB4=Yes LCB4=Yes |
|||||||||
| 01 | Covering rear | GRAU | 1 | 51167145682 | $16.25 | Shop at ECS Tuning | ||||
| For vehicles with Cloth "Fluid" or "Linea"/anthracite or Cloth "blue shadow/Alcantara"/anthracite or Cloth/leather "citrus"/anthracite or Cloth/leather citrus/blue or Cloth/leather citrus/quarz-blue or Sensatec/black or Leather "Dakota"/lemon or Leather "Dakota"/terra or Leather "Dakota"/schwarz |
ALAT=Yes ANAT=Yes FFAT=Yes FFB5=Yes FFB6=Yes KASW=Yes LCB7=Yes LCB8=Yes LCSW=Yes |
|||||||||
| 01 | Covering rear | BEIGE | 1 | 51167145683 | $16.25 | Shop at ECS Tuning | ||||
| For vehicles with Cloth "Fluid" or "Linea"/grey or Leather "Dakota"/grau |
ALAD=Yes LCAD=Yes |
|||||||||
| 02 | Ashtray rear | SCHWARZ | 1 | 51167138525 | $48.46 | Shop at ECS Tuning | ||||
| For vehicles with Cloth "Fluid"/beige or Sensatec/beige or Leather "Dakota"/beige |
ALB4=Yes KAB4=Yes LCB4=Yes |
|||||||||
| 02 | Ashtray rear | GRAU | 1 | 51167138526 | $48.46 | Shop at ECS Tuning | ||||
| For vehicles with Cloth "Fluid" or "Linea"/anthracite or Cloth "blue shadow/Alcantara"/anthracite or Cloth/leather "citrus"/anthracite or Cloth/leather citrus/blue or Cloth/leather citrus/quarz-blue or Sensatec/black or Leather "Dakota"/lemon or Leather "Dakota"/terra or Leather "Dakota"/schwarz |
ALAT=Yes ANAT=Yes FFAT=Yes FFB5=Yes FFB6=Yes KASW=Yes LCB7=Yes LCB8=Yes LCSW=Yes |
|||||||||
| 02 | Ashtray rear | BEIGE | 1 | 51167138527 | $48.46 | Shop at ECS Tuning | ||||
| 03 | Ashtray insert | 1 | 51167156544 | $8.83 | Shop at ECS Tuning | |||||
See Also
Frequently Asked Questions
- What assembly is shown in the BMW 3 Series E90 320d Ashtray rear?
- This technical diagram illustrates the Ashtray rear within the Retrofitting / conversion / accessories group for the 3 Series E90 320d produced during 2007. It provides a detailed exploded view of the components, identifying key parts such as the Covering rear (Part #51167145681).
- Which models use the hardware listed in this Ashtray rear?
- The hardware and components featured in the Ashtray rear are specific to the 3 Series E90 320d produced during 2007. These technical specifications ensure that parts like the Covering rear (51167145681) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Ashtray rear assembly?
- Each item in the Ashtray rear corresponds to the numbered list below the illustration. For the 3 Series E90 320d, you can identify the Covering rear by locating its position on the schematic, which then links to the official BMW part number 51167145681 for the Retrofitting / conversion / accessories section.
