Radio installation kit for BMW 3 Series E46 325xi (2005)
This Radio installation kit technical drawing provides a detailed breakdown of the assembly for the 3 Series E46 325xi. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2005.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| Only for cars with I-Bus | ||||||||||
| 01 | Installation kit | E46/53 SIRIUS | 1 | 84110141976 | $60.00 | Shop at ECS Tuning | ||||
| only in conjunction with | ||||||||||
| 01 | Installation kit | E46/53 CPT-8000 | 1 | 84110150530 | $60.00 | Shop at ECS Tuning | ||||
| only in conjunction with | ||||||||||
| -- | Radio | SIRIUS RECEIVER | 1 | 84110153365 | $275.00 | ENDED | Shop at ECS Tuning | |||
| -- | Antenna kit | LPA SIRIUS G2 | 1 | 84110392099 | $39.99 | ENDED | Shop at ECS Tuning | |||
| 02 | Radio | SIRIUS RECEIVER | 1 | 84110153365 | $275.00 | ENDED | Shop at ECS Tuning | |||
| 03 | Antenna kit | LPA SIRIUS G2 | 1 | 84110392099 | $39.99 | ENDED | Shop at ECS Tuning | |||
Notes
- ENDED = the part has been discontinued (no longer available).
See Also
Frequently Asked Questions
- What assembly is shown in the BMW 3 Series E46 325xi Radio installation kit?
- This technical diagram illustrates the Radio installation kit within the Retrofitting / conversion / accessories group for the 3 Series E46 325xi produced during 2005. It provides a detailed exploded view of the components, identifying key parts such as the Installation kit (Part #84110141976).
- Which models use the hardware listed in this Radio installation kit?
- The hardware and components featured in the Radio installation kit are specific to the 3 Series E46 325xi produced during 2005. These technical specifications ensure that parts like the Installation kit (84110141976) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Radio installation kit assembly?
- Each item in the Radio installation kit corresponds to the numbered list below the illustration. For the 3 Series E46 325xi, you can identify the Installation kit by locating its position on the schematic, which then links to the official BMW part number 84110141976 for the Retrofitting / conversion / accessories section.
