Ski bag for BMW 3 Series E46 320d (2005)
This Ski bag technical drawing provides a detailed breakdown of the assembly for the 3 Series E46 320d. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2005.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| only applies to rear center arm rest | ||||||||||
| 01 | Installing set ski sack | 1 | 72609410808 | $272.95 | ENDED, +core | Shop at ECS Tuning | ||||
Notes
- ENDED = the part has been discontinued (no longer available).
- +core = plus core charge (possibility of a return of the old part)
See Also
Frequently Asked Questions
- What assembly is shown in the BMW 3 Series E46 320d Ski bag?
- This technical diagram illustrates the Ski bag within the Retrofitting / conversion / accessories group for the 3 Series E46 320d produced during 2005. It provides a detailed exploded view of the components, identifying key parts such as the Installing set ski sack (Part #72609410808).
- Which models use the hardware listed in this Ski bag?
- The hardware and components featured in the Ski bag are specific to the 3 Series E46 320d produced during 2005. These technical specifications ensure that parts like the Installing set ski sack (72609410808) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Ski bag assembly?
- Each item in the Ski bag corresponds to the numbered list below the illustration. For the 3 Series E46 320d, you can identify the Installing set ski sack by locating its position on the schematic, which then links to the official BMW part number 72609410808 for the Retrofitting / conversion / accessories section.
