Car phone for Japan for BMW 3 Series E90 335i (2008)
This Car phone for Japan technical drawing provides a detailed breakdown of the assembly for the 3 Series E90 335i. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2008.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| i | For vehicles with National version japan and Navigation system Professional and Preparation f tel.installation universal |
L807A=Yes S609A=Yes S640A=Yes |
||||||||
| 01 | Retrofit kit for car telephone in Japan | 1 | 09/2005 | 84640410284 | ENDED, +core | Shop at ECS Tuning | ||||
Notes
- ENDED = the part has been discontinued (no longer available).
- +core = plus core charge (possibility of a return of the old part)
See Also
Frequently Asked Questions
- What assembly is shown in the BMW 3 Series E90 335i Car phone for Japan?
- This technical diagram illustrates the Car phone for Japan within the Retrofitting / conversion / accessories group for the 3 Series E90 335i produced during 2008. It provides a detailed exploded view of the components, identifying key parts such as the Retrofit kit for car telephone in Japan (Part #84640410284).
- Which models use the hardware listed in this Car phone for Japan?
- The hardware and components featured in the Car phone for Japan are specific to the 3 Series E90 335i produced during 2008. These technical specifications ensure that parts like the Retrofit kit for car telephone in Japan (84640410284) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Car phone for Japan assembly?
- Each item in the Car phone for Japan corresponds to the numbered list below the illustration. For the 3 Series E90 335i, you can identify the Retrofit kit for car telephone in Japan by locating its position on the schematic, which then links to the official BMW part number 84640410284 for the Retrofitting / conversion / accessories section.
