M Performance Parts for BMW 2 Series F87 M2 M2 (2017)
This M Performance Parts technical drawing provides a detailed breakdown of the assembly for the 2 Series F87 M2 M2. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2017.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| i | Note: No other approval documents are required for sport mode. The silencer is approved for use on public roads. When Track mode is used on public roads, the approval lapses. Note: For Mainland China: Retrofitting not following GA-801 2019 is only allowed for use on racetrack and not for use on public roads according to the relevant retrofitting regulation. For vehicles with National version China |
L8AAA=No |
||||||||
| For vehicles with National version Germany |
L801A=No |
|||||||||
| 01 | Exhaust-flap muffler system | M PERFORMANCE | 1 | 01/2017 | 18302454297 | Shop at ECS Tuning | ||||
| only in conjunction with | ||||||||||
| -- | Tailpipe tip in titanium | "M PERFORMANCE" | 1 | 01/2017 | 18302358111 | Shop at ECS Tuning | ||||
| For vehicles with National version China |
L8AAA=Yes |
|||||||||
| 01 | Exhaust-flap muffler system | M PERFORMANCE | 1 | 18302454297 | Shop at ECS Tuning | |||||
| only in conjunction with | ||||||||||
| -- | Tailpipe tip in titanium | "M PERFORMANCE" | 1 | 18302358111 | Shop at ECS Tuning | |||||
| 02 | Remote control for exhaust flap system | M PERFORMANCE | 1 | 18302445006 | Shop at ECS Tuning | |||||
| 03 | Tailpipe end cover in Carbon | "M PERFORMANCE" | 4 | 18302358110 | Shop at ECS Tuning | |||||
| Only suitable for M Performance silencer system |
||||||||||
| 03 | Tailpipe tip in titanium | "M PERFORMANCE" | 4 | 18302358111 | Shop at ECS Tuning | |||||
| Only suitable for M Performance silencer system |
||||||||||
| 04 | Screw | "M PERFORMANCE" | 1 | 18302413820 | Shop at ECS Tuning | |||||
| Spare part | ||||||||||
| 05 | Pipe clamp | M PERFORMANCE | 2 | 18302456695 | Shop at ECS Tuning | |||||
| 06 | Muffler clamp | D=80,0 X 31,8MM | 1 | 18307614699 | Shop at ECS Tuning | |||||
| 07 | Wiring harness for valve-control muffler | M PERFORMANCE | 1 | 18302454298 | Shop at ECS Tuning | |||||
| 08 | Receiver unit, valve-controlled muffler | M PERFORMANCE | 1 | 18302456676 | Shop at ECS Tuning | |||||
| Spare part | ||||||||||
| 09 | Actuator drive, exhaust flap | ERSATZTEIL | 2 | 18302409515 | Shop at ECS Tuning | |||||
