BMW LA wheel M double spoke 648M - 20" for BMW 6 Series G32 GT LCI 620dX (2024)
This BMW LA wheel M double spoke 648M - 20" technical drawing provides a detailed breakdown of the assembly for the 6 Series G32 GT LCI 620dX. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2024.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| i | Note: Only for vehicles with approval in accordance with EU type approval. The selected wheel/tire combination is entry- relevant under certain circumstances. In the vehicle's oxidation catalytic converter, please check whether the wheel/tire combination is entered. If this is not the case, then give the customer either the excerpt from the EU type approval or the Part Certificate of Conformity. Where applicable, a subsequent national approval may be required for a specific country. |
|||||||||
| For vehicles with National version japan and Tire pressure display Runflat tires with emergency running properties Mixed tyres Vorderachse 245/40R20 99Y Rear axle 275/35R20 102Y Pirelli P-Zero r-f |
L807A=No S2VBA=Yes |
|||||||||
| 01 | TPM tire and wheel, summer, Orbitgrey | 1 | 36112473101 | ENDED | Shop at ECS Tuning | |||||
Notes
- ENDED = the part has been discontinued (no longer available).
