MINI toolbox customized for BMW MINI Cabrio F57 LCI JCW (2024)
This MINI toolbox customized technical drawing provides a detailed breakdown of the assembly for the MINI Cabrio F57 LCI JCW. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2024.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| Note: The part shall be ordered with the Motif code. Installability depends on the code. 001 - Boardwalk interior equipment F60 002- Piccadilly interior equipment F56 003- MINI Cooper Anniversary F56 004-Brick Lane interior equipment driver's side F56 005-Brick Lane fender F60 L+R 006-Multitone Sticker sun visor |
||||||||||
| 01 | Sticker size XS without polyurethane | CUSTOMISED | 1 | 51145A35370 | Shop at ECS Tuning | |||||
| Note: The part shall be ordered with the Motif code. 001-Richmond left 002-Richmond right 003-Frozen Brass (fb) 004-Estate 005-Knightsbridge 006- MINI Cooper Anniversary (Heritage) 007-Rockingham GT 008-Jermyn 009-Brick Lane 010-Soho (F54, F60) 011-Jubilee (F56) 012-Pat Moss (F56) 013-20 years USA 014-Multitone |
||||||||||
| 01 | Sticker size XS with polyurethane | CUSTOMISED | 1 | 51145A35369 | Shop at ECS Tuning | |||||
| Note: The part shall be ordered with the Motif code. Installability depends on the code. 001-Dalston hood stripes 002-Boardwalk exterior trim 003-Shadow F60/F5x roof 004-Anniversary "74" for hood 005-Brick Lane F60 roof 006-Soho interior equipment RHD left (F54/F60) 007-Jubilee LHD left F56 008-Jubilee LHD right F56 009-Jubilee trim band front grille 010-Pat Moss interior equipment L+R 011-Pat Moss sticker side panel (SiSc) 012-20 years USA interior equipment L+R 013-20 years USA sticker tailgate 014-Highlands kit roof sticker F60 PHEV |
||||||||||
| 01 | Sticker size M | CUSTOMISED | 1 | 51145A35372 | Shop at ECS Tuning | |||||
| Note: The part shall be ordered with the Motif code. Installability depends on the code. 001 - F56 GP inspired 002- F54 GP inspired 003 - F60 GP inspired 004- F55/F56 Piccadilly Melting Silver hood stripes 005-20 years USA shoulder left F55 006-20 years USA shoulder right F55 007- 20 years USA hood F55 |
||||||||||
| 01 | Sticker size L | CUSTOMISED | 1 | 51145A36A95 | Shop at ECS Tuning | |||||
| Note: The part shall be ordered with the Motif code. Installability depends on the code. 001-F56 Rockingham GT side stripes 002-F60 Shadow right fender 003-F60 Shadow left fender 004-F54 Shadow right fender 005-F54 Shadow left fender 006-F5x/F60 Shadow hood 007-F54 Active Gentleman left side 008-F54 Active Gentleman right side 009-F54 Active Gentleman hood 010-F54 Estate car wrapping on side (l+r) 011-F60 Estate car wrapping on side (l+r) 012-F54 Savile Row Melting Silver hood 013-F54 Savile Row Melting Silver left side 014-F54 Savile Row Melting Silver right side 015-F54 Savile Row Black left side 016-F54 Savile Row Black right side 017-F54 Savile Row Black hood 018-F55 Piccadilly Melting Silver exterior trim kit 019-F56 Piccadilly Melting Silver exterior trim kit 020-F56 Shadow right fender 021-F56 Shadow left fender 022-F56 Anniversary MINI Cooper car wrapping on side (l+r) 023-F56 Anniversary MINI Cooper hood 024-F56 Rockingham GT hood kit 025-F54 Jermyn Melting Silver left side 026-F54 Jermyn Melting Silver right side 027-F54 Jermyn Melting Silver hood 028-F54 Jermyn Black hood 029-F54 Jermyn Black left side 030-F54 Jermyn Black right side 031-F56 Brick Lane side l+r 032-F54 Brick Lane side l+r 033-F60 Brick Lane side l+r 034-F56 Brick Lane hood 035-F54 Brick Lane hood 036-F60 Brick Lane hood 037-F54 Rockingham GT hood 038-F60 Rockingham GT hood 039-F54 Rockingham GT side l+r 040-F55 Rockingham GT side l+r 041-F60 Rockingham GT side l+r Note: The part shall be ordered with the Motif code. Installability depends on the code. 001-F56 Rockingham GT shoulder 002-F60 Shadow fender right 003-F60 Shadow fender left 004-F54 Shadow fender right 005-F54 Shadow fender left 006-F5x/F60 Shadow hood 007-F54 Active Gentleman side left 008-F54 Active Gentleman side right 009-F54 Active Gentleman hood 010-F54 Estate side wrapping (L+R) 011-F60 Estate side wrapping (L+R) 012-F54 Savile Row melting silver hood 013-F54 Savile Row melting silver side left 014-F54 Savile Row melting silver side right 015-F54 Savile Row black side left 016-F54 Savile Row black side right 017-F54 Savile Row black hood 018-F55 Piccadilly Melting Silver kit exterior trim 019-F56 Piccadilly Melting Silver kit exterior trim 020-F56 Shadow fender right 021-F56 Shadow fender left 022-F56 Anniversary MINI Cooper side wrapping (L+R) 023-F56 Anniversary MINI Cooper hood 024-F56 Rockingham GT kit hood 025-F54 Jermyn Melting Silver side left 026-F54 Jermyn Melting Silver side right 027-F54 Jermyn Melting Silver hood 028-F54 Jermyn Black hood 029-F54 Jermyn Black side left 030-F54 Jermyn Black side right 031-F56 Brick Lane side L+R 032-F54 Brick Lane side L+R 033-F60 Brick Lane side L+R 034-F56 Brick Lane hood 035-F54 Brick Lane hood 036-F60 Brick Lane hood 037-F54 Rockingham GT hood 038-F60 Rockingham GT hood 039-F54 Rockingham GT side L+R 040-F55 Rockingham GT side L+R 041-F60 Rockingham GT side L+R 042-F56 The Coopers hood 043-F56 Jubilee Front left 044-F56 Jubilee Front right 045-F56 Pat Moss hood |
||||||||||
| 01 | Sticker size XL | CUSTOMISED | 1 | 51145A35373 | Shop at ECS Tuning | |||||
| Note: The part shall be ordered with the Motif code. Installability depends on the code. 001-Dalston interior equipment 002-Rockingham GT interior equipment 003-F54 Shadow interior equipment 004-F60 Shadow interior equipment 005-F56 GP Inspired interior equipment 006-F60 GP Inspired interior equipment 007-F54 GP Inspired interior equipment 008-GP Inspired hood scoop 009- GP Inspired C-Pillar 010-Piccadilly exterior trim Black 011-Piccadilly exterior trim White 012-Camden interior equipment 013-F54 Estate interior equipment 014-F60 Estate interior equipment 015-F56 Anniversary Door Sticker B- pillar 016-F56 Anniversary interior equipment Signing 017-F54 Jermyn interior equipment 018-F54 Rockingham GT interior equipment 019-F60 Brick Lane interior equipment 020-F5x Brick Lane interior equipment 021-F56 Rockingham GT interior equipment (driver's side) 022-F5x/F60 Rockingham GT (passenger's side) Note: The part shall be ordered with the Motif code. Installability depends on the code. 001-Dalston interior equipment 002-Rockingham GT interior equipment 003-F54 Shadow interior equipment 004-F60 Shadow interior equipment 005-F56 GP Inspired interior equipment 006-F60 GP Inspired interior equipment 007-F54 GP Inspired interior equipment 008-GP Inspired hood scoop 009- GP Inspired C-pillar 010-Piccadilly exterior trim black 011-Piccadilly exterior trim white 012-Camden interior equipment 013-F54 Estate interior equipment 014-F60 Estate interior equipment 015-F56 Anniversary door sticker B- pillar 016-F56 Anniversary interior equipment signing 017-F54 Jermyn interior equipment 018-F54 Rockingham GT interior equipment 019-F60 Brick Lane interior equipment 020-F5x Brick Lane interior equipment 021-F56 Rockingham GT interior equipment (driver's side) 022-F5x/F60 Rockingham GT (front passenger side) 023-The Coopers (CN) interior equipment F56 (driver's side) 024-Pat Moss front sticker (lettering) F56 025-Highlands sticker tailgate F60 026-Highlands interior equipment sticker F60 |
||||||||||
| 01 | Sticker size S | CUSTOMISED | 1 | 51145A35371 | Shop at ECS Tuning | |||||
| Note: The part shall be ordered with the Motif code. Installability depends on the code. 001-Camden, 002-Piccadilly, 003- Rockingham GT, 004-Shadow, 005- Anniversary, 006-Brick Lane |
||||||||||
| 02 | Trim cover set with pad | CUSTOMISED | 1 | 51135A34729 | Shop at ECS Tuning | |||||
| Note: Key cap must be ordered with motif code: 006: Multitone Edition 005: Knightsbridge edition 004: Frozen Blue Edition 003: Frozen Brass Edition 002: Paddy Hopkirk Edition 001: GP Pack Edition |
||||||||||
| 03 | Key cap | CUSTOMISED | 1 | 82295A36D50 | Shop at ECS Tuning | |||||
| Note: Part must be ordered via motif code. 505: F54 Final Edition (Shimmer Cooper Metallic) 504: F57 Seaside Edition (Deep Laguna) 501: Brick Lane (Frozen Blue) 506: F60 Uncharted (Black Metallic) 507: F55, F56 Mayfield (Black Metallic) 508: F56 JCW 1 To 6 (Black Metallic) 509: F56 Paul Smith (Black Metallic) |
||||||||||
| 03 | Key cap | CUSTOM. COATED | 1 | 82295A36D99 | Shop at ECS Tuning | |||||
| Note: Part must be ordered with Motif code 007: F56 GT Edition 006: Piccadilly Edition 005: Rosewood Edition 004: We Are Code Blooded (ARHS) Edition 003: First Edition 002: Deloitte Edition 001: Paddy Hopkirk Edition |
||||||||||
| 04 | MINI LED door sill cov.strip Customised | F56, F57 | 1 | 51475A33F12 | Shop at ECS Tuning | |||||
