MINI toolbox color lines for BMW MINI Cabrio F57 LCI JCW (2024)
This MINI toolbox color lines technical drawing provides a detailed breakdown of the assembly for the MINI Cabrio F57 LCI JCW. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2024.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Trim ring, headlight, left | ASPEN WHITE | 1 | 51719629577 | Shop at ECS Tuning | |||||
| 01 | Trim ring, headlight, right | ASPEN WHITE | 1 | 51719629578 | Shop at ECS Tuning | |||||
| 01 | Trim ring, headlight, left | FROZEN BRASS | 1 | 51719629579 | Shop at ECS Tuning | |||||
| 01 | Trim ring, headlight, right | FROZEN BRASS | 1 | 51719629580 | Shop at ECS Tuning | |||||
| 01 | Trim ring, headlight, left | FROZEN BLUE | 1 | 51719629583 | Shop at ECS Tuning | |||||
| 01 | Trim ring, headlight, right | FROZEN BLUE | 1 | 51719629584 | Shop at ECS Tuning | |||||
| 02 | Trim ring tail light, left | ASPEN WHITE | 1 | 51719624307 | Shop at ECS Tuning | |||||
| 02 | Trim ring tail light right | ASPEN WHITE | 1 | 51719625906 | Shop at ECS Tuning | |||||
| 02 | Trim ring tail light, left | FROZEN BRASS | 1 | 51719625911 | Shop at ECS Tuning | |||||
| 02 | Trim ring tail light right | FROZEN BRASS | 1 | 51719625912 | Shop at ECS Tuning | |||||
| 02 | Trim ring tail light, left | FROZEN BLUE | 1 | 51719625919 | Shop at ECS Tuning | |||||
| 02 | Trim ring tail light right | FROZEN BLUE | 1 | 51719625920 | Shop at ECS Tuning | |||||
| 05 | Trunk lid grip | ASPEN WHITE | 1 | 03/2018 | 51719629576 | Shop at ECS Tuning | ||||
| 05 | Trunk lid grip | FROZEN BRASS | 1 | 03/2018 | 51719629581 | Shop at ECS Tuning | ||||
| 05 | Trunk lid grip | FROZEN BLUE | 1 | 03/2018 | 51719629582 | Shop at ECS Tuning | ||||
| 06 | Tankeinfuellklappe | ASPEN WHITE | 1 | 51712470383 | Shop at ECS Tuning | |||||
| 06 | Tankeinfuellklappe | FROZEN BRASS | 1 | 51719625908 | Shop at ECS Tuning | |||||
| 06 | Tankeinfuellklappe | FROZEN BLUE | 1 | 51719625916 | Shop at ECS Tuning | |||||
| 07 | Türaussengriff links LHD | ASPEN WHITE | 1 | 51719624261 | Shop at ECS Tuning | |||||
| 07 | External door handle, left, RHD | ASPEN WHITE | 1 | 51719624262 | Shop at ECS Tuning | |||||
| 07 | Türaussengriff links LHD | FROZEN BRASS | 1 | 51719625930 | Shop at ECS Tuning | |||||
| 07 | External door handle, left, RHD | FROZEN BRASS | 1 | 51719625931 | Shop at ECS Tuning | |||||
| 07 | Türaussengriff links LHD | FROZEN BLUE | 1 | 51719625937 | Shop at ECS Tuning | |||||
| 07 | External door handle, left, RHD | FROZEN BLUE | 1 | 51719625938 | Shop at ECS Tuning | |||||
| 08 | MINI Emblem vorne | ASPEN WHITE | 1 | 51145A18080 | Shop at ECS Tuning | |||||
| 08 | MINI badge rear | ASPEN WHITE | 1 | 51145A18089 | Shop at ECS Tuning | |||||
| 08 | MINI Emblem vorne | FROZEN BRASS | 1 | 51145A18090 | Shop at ECS Tuning | |||||
| 08 | MINI badge rear | FROZEN BRASS | 1 | 51145A18099 | Shop at ECS Tuning | |||||
| 08 | MINI Emblem vorne | FROZEN BLUE | 1 | 51145A180A0 | Shop at ECS Tuning | |||||
| 08 | MINI badge rear | FROZEN BLUE | 1 | 51145A180A3 | Shop at ECS Tuning | |||||
| For vehicles with Active cruise control |
S541A=No |
|||||||||
| 09 | Trim ring center console inner | FROZEN BRASS | 1 | 51165A45BC0 | ENDED | Shop at ECS Tuning | ||||
| 09 | Trim ring center console inner | FROZEN BLUE | 1 | 51165A45BD0 | Shop at ECS Tuning | |||||
Notes
- ENDED = the part has been discontinued (no longer available).
