Brick Lane Edition for BMW MINI Cabrio F57 LCI JCW (2024)
This Brick Lane Edition technical drawing provides a detailed breakdown of the assembly for the MINI Cabrio F57 LCI JCW. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 2024.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Tankeinfuellklappe | FROZEN BLUE | 1 | 51719625916 | Shop at ECS Tuning | |||||
| 02 | Trim ring tail light, left | FROZEN BLUE | 1 | 51719625919 | Shop at ECS Tuning | |||||
| 02 | Trim ring tail light right | FROZEN BLUE | 1 | 51719625920 | Shop at ECS Tuning | |||||
| 03 | Türaussengriff links LHD | FROZEN BLUE | 1 | 51719625937 | Shop at ECS Tuning | |||||
| 03 | External door handle right LHD | FROZEN BLUE | 1 | 51719625940 | Shop at ECS Tuning | |||||
| 03 | Door handle, outside, rear left | FROZEN BLUE | 1 | 51719625941 | Shop at ECS Tuning | |||||
| 03 | Door handle, outside, rear right | FROZEN BLUE | 1 | 51719625942 | Shop at ECS Tuning | |||||
| 04 | Trunk lid grip | FROZEN BLUE | 1 | 51719629582 | Shop at ECS Tuning | |||||
| 05 | Trim ring, headlight, left | FROZEN BLUE | 1 | 51719629583 | Shop at ECS Tuning | |||||
| 05 | Trim ring, headlight, right | FROZEN BLUE | 1 | 51719629584 | Shop at ECS Tuning | |||||
| 06 | MINI Emblem vorne | FROZEN BLUE | 1 | 51145A180A0 | Shop at ECS Tuning | |||||
| 06 | MINI badge rear | FROZEN BLUE | 1 | 51145A180A3 | Shop at ECS Tuning | |||||
| Note: Part must be ordered with Motif code 006-Brick Lane |
||||||||||
| 07 | Trim cover set with pad | CUSTOMISED | 1 | 51135A34729 | Shop at ECS Tuning | |||||
| Note: Part must be ordered with Motif code 009-Brick Lane |
||||||||||
| 08 | Sticker size XS with polyurethane | CUSTOMISED | 2 | 51145A35369 | Shop at ECS Tuning | |||||
| Note: Part must be ordered with Motif code 004-Brick Lane |
||||||||||
| 09 | Sticker size XS without polyurethane | CUSTOMISED | 1 | 51145A35370 | Shop at ECS Tuning | |||||
| Note: Part must be ordered with Motif code 020-Brick Lane |
||||||||||
| 10 | Sticker size S | CUSTOMISED | 1 | 51145A35371 | Shop at ECS Tuning | |||||
| 11 | Brick Lane shoulder l+r | MINI TOOLBOX | 1 | 51145A70FB9 | Shop at ECS Tuning | |||||
| Note: Part must be ordered with Motif code 501-Brick Lane |
||||||||||
| 12 | Key cap | CUSTOM. COATED | 1 | 82295A36D99 | Shop at ECS Tuning | |||||
| For vehicles with Active cruise control |
S541A=No |
|||||||||
| 13 | Trim ring center console inner | FROZEN BLUE | 1 | 51165A45BD0 | Shop at ECS Tuning | |||||
| 14 | Entrance strip, front | F56 BRICK LANE | 2 | 51775A4F619 | Shop at ECS Tuning | |||||
| 14 | Adhesive pad, front | 2 | 51777403242 | Shop at ECS Tuning | ||||||
| 15 | Hub cap fixed Bricklane | MINI | 1 | 36125A50040 | Shop at ECS Tuning | |||||
| 16 | Floor mats emblem | BRICK LANE | 1 | 51475A55A71 | Shop at ECS Tuning | |||||
| 17 | Brick Lane Bonnet | MINI TOOLBOX | 1 | 51145A70FD3 | Shop at ECS Tuning | |||||
