Crankshaft-Pistons for BMW 3 Series E30 320i (1990)
This Crankshaft-Pistons technical drawing provides a detailed breakdown of the assembly for the 3 Series E30 320i. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1990.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Mahle piston | 79,980MM("0") | 6 | 09/1987 | 11251705322 | $222.39 | Shop at ECS Tuning | |||
| 01 | Mahle piston | 80,060MM("00") | 6 | 09/1987 | 11251705323 | ENDED | Shop at ECS Tuning | |||
| 01 | Mahle piston | 80,230MM(+0,25) | 6 | 09/1987 | 11251705324 | $157.36 | Shop at ECS Tuning | |||
| 01 | Mahle piston | 80,480MM(+0,50) | 6 | 09/1987 | 11251705325 | ENDED | Shop at ECS Tuning | |||
| 01 | Borgo piston | 79,980MM("0") | 6 | 09/1987 | 11251720532 | ENDED | Shop at ECS Tuning | |||
| 01 | Borgo piston | 79,980MM("0") | 6 | 09/1987 | 11251730399 | Shop at ECS Tuning | ||||
| 01 | Borgo piston | 80,060MM("00") | 6 | 09/1987 | 11251730400 | ENDED | Shop at ECS Tuning | |||
| For vehicles with National version Switzerland or National version Australia or National version sweden |
L804A=Yes L810A=Yes V010A=Yes |
|||||||||
| 01 | Mahle piston | 79,980MM("0") | 6 | 09/1983 | 11251705322 | $222.39 | Shop at ECS Tuning | |||
| 01 | Mahle piston | 80,060MM("00") | 6 | 09/1983 | 11251705323 | ENDED | Shop at ECS Tuning | |||
| 01 | Mahle piston | 80,230MM(+0,25) | 6 | 09/1983 | 11251705324 | $157.36 | Shop at ECS Tuning | |||
| 01 | Mahle piston | 80,480MM(+0,50) | 6 | 09/1983 | 11251705325 | ENDED | Shop at ECS Tuning | |||
Notes
- ENDED = the part has been discontinued (no longer available).
See Also
Frequently Asked Questions
- What assembly is shown in the BMW 3 Series E30 320i Crankshaft-Pistons?
- This technical diagram illustrates the Crankshaft-Pistons within the Engine group for the 3 Series E30 320i produced during 1990. It provides a detailed exploded view of the components, identifying key parts such as the Mahle piston (Part #11251705322).
- Which models use the hardware listed in this Crankshaft-Pistons?
- The hardware and components featured in the Crankshaft-Pistons are specific to the 3 Series E30 320i produced during 1990. These technical specifications ensure that parts like the Mahle piston (11251705322) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Crankshaft-Pistons assembly?
- Each item in the Crankshaft-Pistons corresponds to the numbered list below the illustration. For the 3 Series E30 320i, you can identify the Mahle piston by locating its position on the schematic, which then links to the official BMW part number 11251705322 for the Engine section.
