Cooling system-thermostat/water hoses for BMW 5 Series E12 530i (1975)
This Cooling system-thermostat/water hoses technical drawing provides a detailed breakdown of the assembly for the 5 Series E12 530i. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1975.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Hose | 1 | 11531266462 | $26.90 | Shop at ECS Tuning | |||||
| 02 | Hose clamp | L=47-54MM | 1 | 07129952121 | $1.42 | Shop at ECS Tuning | ||||
| 03 | Hex bolt | M6X25 | 4 | 07119913589 | $0.62 | Shop at ECS Tuning | ||||
| 04 | Spring washer Black | B6-ZN | 4 | 07119932073 | $0.38 | Shop at ECS Tuning | ||||
| 05 | Cover | 1 | 11531714861 | $80.96 | Shop at ECS Tuning | |||||
| 06 | Vent screw | M8 | 1 | 11531275881 | $3.47 | Shop at ECS Tuning | ||||
| 07 | Gasket Asbestos Free | 1 | 11531250357 | $1.52 | ENDED | Shop at ECS Tuning | ||||
| 08 | Thermostat | 80 CEL | 1 | 11531251041 | $29.57 | Shop at ECS Tuning | ||||
| only in conjunction with | ||||||||||
| -- | O-ring | 1 | 11531250399 | $1.98 | Shop at ECS Tuning | |||||
| only applies to | ||||||||||
| -- | Thermostat housing | X | 11531250352 | ENDED | Shop at ECS Tuning | |||||
| -- | Thermostat housing | X | 11531272870 | ENDED | Shop at ECS Tuning | |||||
| 09 | O-ring | 1 | 11531250399 | $1.98 | Shop at ECS Tuning | |||||
| only applies to | ||||||||||
| -- | Thermostat housing | X | 11531250352 | ENDED | Shop at ECS Tuning | |||||
| -- | Thermostat | 80 GRAD | X | 11531254065 | $62.16 | ENDED | Shop at ECS Tuning | |||
| -- | Thermostat housing | X | 11531272870 | ENDED | Shop at ECS Tuning | |||||
Notes
- ENDED = the part has been discontinued (no longer available).
See Also
Frequently Asked Questions
- What assembly is shown in the BMW 5 Series E12 530i Cooling system-thermostat/water hoses?
- This technical diagram illustrates the Cooling system-thermostat/water hoses within the Engine group for the 5 Series E12 530i produced during 1975. It provides a detailed exploded view of the components, identifying key parts such as the Hose (Part #11531266462).
- Which models use the hardware listed in this Cooling system-thermostat/water hoses?
- The hardware and components featured in the Cooling system-thermostat/water hoses are specific to the 5 Series E12 530i produced during 1975. These technical specifications ensure that parts like the Hose (11531266462) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Cooling system-thermostat/water hoses assembly?
- Each item in the Cooling system-thermostat/water hoses corresponds to the numbered list below the illustration. For the 5 Series E12 530i, you can identify the Hose by locating its position on the schematic, which then links to the official BMW part number 11531266462 for the Engine section.
