Intake manifold system for BMW 6 Series E24 633CSi (1979)
This Intake manifold system technical drawing provides a detailed breakdown of the assembly for the 6 Series E24 633CSi. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1979.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Holder | 1 | 09/1981 | 11611266133 | $1.98 | ENDED | Shop at ECS Tuning | |||
| 02 | Hex bolt | M6X16-8.8-ZNS3 | 1 | 09/1981 | 07119904357 | $0.36 | Shop at ECS Tuning | |||
| 03 | Gasket Asbestos Free | 6 | 09/1981 | 11611730788 | $2.54 | Shop at ECS Tuning | ||||
| 03 | Gasket Asbestos Free | 6 | 09/1981 | 11619065676 | $4.18 | Shop at ECS Tuning | ||||
| 04 | Intake manifold | ZYL.1-3 | 1 | 09/1981 | 11611256415 | $75.96 | ENDED | Shop at ECS Tuning | ||
| 04 | Intake manifold | ZYL.4-6 | 1 | 09/1981 | 11611256418 | $68.24 | Shop at ECS Tuning | |||
| 05 | Gasket Asbestos Free | 6 | 09/1981 | 11611730742 | $3.80 | Shop at ECS Tuning | ||||
| 06 | Suction pipe | 3 | 09/1981 | 11611256567 | $38.67 | ENDED | Shop at ECS Tuning | |||
| 07 | Suction pipe | 3 | 09/1981 | 11611259117 | $28.83 | ENDED | Shop at ECS Tuning | |||
| 08 | Wave washer | 8,4X15-ZNS3 | X | 09/1981 | 07119904115 | $0.09 | Shop at ECS Tuning | |||
| 09 | Hex nut wiht flange | M8 | X | 09/1981 | 11611713432 | $0.43 | ENDED | Shop at ECS Tuning | ||
| 10 | Stud bolt | M8X40 | 9 | 09/1981 | 07129903964 | Shop at ECS Tuning | ||||
| 11 | Stud bolt | M8X28-ZN | 3 | 09/1981 | 07119908368 | $0.54 | Shop at ECS Tuning |
Notes
- ENDED = the part has been discontinued (no longer available).
