Connecting rod / Connecting rod bearing for BMW R45-R65LS..78-85 R65 (1980)
This Connecting rod / Connecting rod bearing technical drawing provides a detailed breakdown of the assembly for the R45-R65LS..78-85 R65. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1980.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Stop disk | 2.483-2.530 | 2 | 11111256973 | $35.31 | Shop at ECS Tuning | ||||
| 01 | Stop disk | 2.530-2.578 | 2 | 11111256974 | $35.31 | Shop at ECS Tuning | ||||
| 01 | Stop disk | 2.578-2.626 | 2 | 11111256975 | $35.31 | Shop at ECS Tuning | ||||
| 01 | Stop disk | 2.626-2.673 | 2 | 11111256976 | $35.31 | Shop at ECS Tuning | ||||
| 02 | Shaft seal | 80X100X10 | 1 | 11111338342 | $33.41 | Shop at ECS Tuning | ||||
| 03 | Bearing bush red | 0.00 | 2 | 11111250155 | $74.96 | Shop at ECS Tuning | ||||
| 03 | Bearing bush blue | 0.00 | 2 | 11111255285 | $68.19 | Shop at ECS Tuning | ||||
| 03 | Bearing bush yellow | 0.00 | 2 | 11111337614 | $68.19 | Shop at ECS Tuning | ||||
| 03 | Bearing bush green | 0.00 | 2 | 11111265437 | $68.19 | Shop at ECS Tuning | ||||
| 03 | Bearing bush red | 0.25 | 2 | 11111254788 | $68.19 | Shop at ECS Tuning | ||||
| 03 | Bearing bush blue | 0.25 | 2 | 11111255286 | $68.19 | Shop at ECS Tuning | ||||
| 03 | Bearing bush yellow | 0.25 | 2 | 11111337725 | Shop at ECS Tuning | |||||
| 03 | Bearing bush green | 0.25 | 2 | 11111337724 | $68.19 | ENDED | Shop at ECS Tuning | |||
| 03 | Bearing bush red | 0.50 | 2 | 11111254789 | $68.19 | Shop at ECS Tuning | ||||
| 03 | Bearing bush blue | 0.50 | 2 | 11111255287 | $68.19 | ENDED | Shop at ECS Tuning | |||
| 03 | Bearing bush red | 0.75 | 2 | 11111255288 | ENDED | Shop at ECS Tuning | ||||
| 03 | Bearing bush blue | 0.75 | 2 | 11111255289 | Shop at ECS Tuning | |||||
| 04 | Woodruff key | 5X6.5 | 1 | 07119951480 | $0.88 | Shop at ECS Tuning | ||||
| 05 | Bearing shell | 0.00 | 4 | 11241258460 | $14.80 | SI 1108198(808) | Shop at ECS Tuning | |||
| 05 | Bearing shell | 0.25 | 4 | 11241258419 | $18.50 | Shop at ECS Tuning | ||||
| 05 | Bearing shell | 0.50 | 4 | 11241258420 | $18.50 | ENDED | Shop at ECS Tuning | |||
| 05 | Bearing shell | 0.75 | 4 | 11241258421 | $18.50 | ENDED | Shop at ECS Tuning |
Notes
- ENDED = the part has been discontinued (no longer available).
- SI = Service Information
See Also
Frequently Asked Questions
- What assembly is shown in the BMW R45-R65LS..78-85 R65 Connecting rod / Connecting rod bearing?
- This technical diagram illustrates the Connecting rod / Connecting rod bearing within the Engine group for the R45-R65LS..78-85 R65 produced during 1980. It provides a detailed exploded view of the components, identifying key parts such as the Stop disk (Part #11111256973).
- Which models use the hardware listed in this Connecting rod / Connecting rod bearing?
- The hardware and components featured in the Connecting rod / Connecting rod bearing are specific to the R45-R65LS..78-85 R65 produced during 1980. These technical specifications ensure that parts like the Stop disk (11111256973) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Connecting rod / Connecting rod bearing assembly?
- Each item in the Connecting rod / Connecting rod bearing corresponds to the numbered list below the illustration. For the R45-R65LS..78-85 R65, you can identify the Stop disk by locating its position on the schematic, which then links to the official BMW part number 11111256973 for the Engine section.
