Radiator for BMW 2500-3.3Li 3.0S (1973)
This Radiator technical drawing provides a detailed breakdown of the assembly for the 2500-3.3Li 3.0S. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1973.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | Hose | 1 | 09/1973 | 02/1977 | 11531266462 | $26.90 | Shop at ECS Tuning | |||
| 02 | Hose clamp | L42-48 | 4 | 07129952119 | $1.15 | Shop at ECS Tuning | ||||
| 03 | Cover | 1 | 11531714861 | $80.96 | Shop at ECS Tuning | |||||
| 04 | Vent screw | M8 | 1 | 11531275881 | $3.47 | Shop at ECS Tuning | ||||
| 05 | Gasket Asbestos Free | 1 | 11531250357 | $1.52 | ENDED | Shop at ECS Tuning | ||||
| 07 | O-ring | 1 | 11531250399 | $1.98 | Shop at ECS Tuning | |||||
| 08 | Gasket Asbestos Free | 1 | 11531722690 | $6.02 | Shop at ECS Tuning | |||||
| 09 | Gasket ring | A14X18-AL | 2 | 07119963200 | $0.38 | Shop at ECS Tuning | ||||
| 10 | Engine coolant temp sensor | 1 | 62111268355 | Shop at ECS Tuning | ||||||
| FG -> | ||||||||||
| 11 | Thermovalve | 1 | 09/1973 | 02/1977 | 11741263742 | $56.37 | Shop at ECS Tuning | |||
| 12 | Vacuum hose black | 3,5X1,8 | X | 09/1973 | 02/1977 | 11727545323 | $14.82 | Shop at ECS Tuning | ||
| 13 | Wave washer | 8,4X15-ZNS3 | 3 | 07119904115 | $0.09 | Shop at ECS Tuning | ||||
| 14 | Hex nut wiht flange | M8 | 3 | 11611713432 | $0.43 | ENDED | Shop at ECS Tuning | |||
| FG -> | ||||||||||
| 15 | Thermostat housing | 1 | 09/1973 | 02/1977 | 11531710959 | $58.65 | Shop at ECS Tuning | |||
| only in conjunction with | ||||||||||
| -- | O-ring | 60X3,5 | 1 | 09/1973 | 02/1977 | 11531265084 | $2.10 | Shop at ECS Tuning | ||
| -- | Thermostat | 1 | 09/1973 | 02/1977 | 11531466174 | $37.00 | Shop at ECS Tuning | |||
| -- | Thermostat | 80CEL | 1 | 09/1973 | 02/1977 | 11531710953 | Shop at ECS Tuning | |||
| -> FG | ||||||||||
| 15 | Thermostat housing | 1 | 11531710959 | $58.65 | Shop at ECS Tuning | |||||
| only in conjunction with | ||||||||||
| -- | O-ring | 60X3,5 | 1 | 11531265084 | $2.10 | Shop at ECS Tuning | ||||
| -- | Thermostat | 1 | 11531466174 | $37.00 | Shop at ECS Tuning | |||||
| -- | Thermostat | 80CEL | 1 | 11531710953 | Shop at ECS Tuning | |||||
| 16 | Hose | 1 | 08/1968 | 02/1977 | 11531266461 | $36.63 | ENDED | Shop at ECS Tuning | ||
| 17 | Water hose | 1 | 11531266459 | $18.87 | Shop at ECS Tuning | |||||
| 18 | Hose clamp | L42-48 | 2 | 07129952119 | $1.15 | Shop at ECS Tuning | ||||
| 20 | Hex bolt | M6X25 | 4 | 07119913483 | $0.36 | Shop at ECS Tuning | ||||
Notes
- ENDED = the part has been discontinued (no longer available).
See Also
Frequently Asked Questions
- What assembly is shown in the BMW 2500-3.3Li 3.0S Radiator?
- This technical diagram illustrates the Radiator within the Radiator group for the 2500-3.3Li 3.0S produced during 1973. It provides a detailed exploded view of the components, identifying key parts such as the Hose (Part #11531266462).
- Which models use the hardware listed in this Radiator?
- The hardware and components featured in the Radiator are specific to the 2500-3.3Li 3.0S produced during 1973. These technical specifications ensure that parts like the Hose (11531266462) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Radiator assembly?
- Each item in the Radiator corresponds to the numbered list below the illustration. For the 2500-3.3Li 3.0S, you can identify the Hose by locating its position on the schematic, which then links to the official BMW part number 11531266462 for the Radiator section.
