Short engine for BMW 3 Series E36 M3 (1999)
This Short engine technical drawing provides a detailed breakdown of the assembly for the 3 Series E36 M3. It includes part names, part numbers and all associated mounting hardware for vehicles produced between 1999.
| No. | Description | Supp. | Qty | From | Up To | Part Number | Price | Notes | ||
|---|---|---|---|---|---|---|---|---|---|---|
| 01 | RP engine | 326S1 | 1 | 11001405256 | +core | Shop at ECS Tuning | ||||
| 01 | RP REMAN engine | 326S1 | 1 | 11001405257 | ENDED, +core | Shop at ECS Tuning | ||||
| 02 | Set Mounting Parts Short Engine | 1 | 11009065090 | $184.73 | Shop at ECS Tuning |
Notes
- +core = plus core charge (possibility of a return of the old part)
- ENDED = the part has been discontinued (no longer available).
See Also
Frequently Asked Questions
- What assembly is shown in the BMW 3 Series E36 M3 Short engine?
- This technical diagram illustrates the Short engine within the Engine group for the 3 Series E36 M3 produced during 1999. It provides a detailed exploded view of the components, identifying key parts such as the RP engine (Part #11001405256).
- Which models use the hardware listed in this Short engine?
- The hardware and components featured in the Short engine are specific to the 3 Series E36 M3 produced during 1999. These technical specifications ensure that parts like the RP engine (11001405256) are correctly matched to the vehicle's structural and mechanical requirements.
- How do I find specific parts within the Short engine assembly?
- Each item in the Short engine corresponds to the numbered list below the illustration. For the 3 Series E36 M3, you can identify the RP engine by locating its position on the schematic, which then links to the official BMW part number 11001405256 for the Engine section.
